Xinje XD Series User Manual

299
station number is
1).
HD8
-
-
-
-
Gateway
address low 2-
byte
Note: The table does not contain "buffer digits" in free communication mode, so "buffer
digits" can not be read and written through CFGCR and CFGCW instructions, but can be read
and written using MOV instructions. The address of "buffer digits" is shown in Appendix 3.
Table 1: baud rate
Value
Baud rate
Value
Baud rate
Value
Baud rate
Value
Baud rate
1
300 bps
7
19200 bps
13
256000 bps
19
1000000 bps
2
600 bps
8
28800 bps
14
288000 bps
20
1200000 bps
3
1200 bps
9
38400 bps
15
384000 bps
21
1500000 bps
4
2400 bps
10
57600 bps
16
512000 bps
22
2400000 bps
5
4800 bps
11
115200 bps
17
576000 bps
23
3000000 bps
6
9600 bps
12
192000 bps
18
768000 bps
Table 2: frame format
Stop bit
Parity bit
Data bit length
Bit7
Bit6
Bit5
Bit4
Bit3
Bit2
Bit1
Bit0
00: 1
01: 1.5
10: 2
000: no
001: odd
010: even
011: empty
100: Mask
000: 5
001: 6
010: 7
011: 8
100: 9
