Xinje XD Series User Manual

30
S
Flow
S0~S1023
1024
HS
HS0~HS127
※1
128
T
Timer
T0~T575
576
HT
HT0~HT95
※1
96
ET
precise timer ET0~ET31
32
C
Counter
C0~C575
576
HC
HC0~HC95
※1
96
HSC
high speed counter HSC0~HSC31
32
D
Data register
D0~D7999
8000
HD
HD0~HD999
※1
1000
SD
special purpose SD0~SD2047
2048
HSD
special purpose HSD0~HSD499
※2
500
FD
FlashROM
register
FD0~FD5119
5120
SFD
special purpose SFD0~SFD1999
※2
2000
FS
Special secret
register
FS0~FS47
48
ID
※6
Main body
ID0~ID99
100
Expansion module
ID10000~ID10099(#1 expansion
module)
……
ID10900~ID10999(#10 expansion
module)
1000
expansion BD
ID20000~ID20099(#1expansionBD)
ID20100~ID20199(#2expansionBD)
200
expansion ED
ID30000~ID30099(#1expansionED)
100
QD
※7
Main body
QD0~QD99
100
Expansion module
QD10000~QD10099(#1 expansion
module)
……
QD10900~QD10999(#10 expansion
module)
1000
expansion BD
QD20000~QD20099(#1expansionBD)
QD20100~QD20199(#2expansionBD)
200
expansion ED
QD30000~QD30099(#1expansionED)
100
SEM
Special coil of
Sequence block
instruction WAIT
SEM0~SEM31
32
XL3 series PLC soft components list:
Name
Range
Points
16 I/O
32 I/O
16
32
X
Input points
X0~X7
X0~X17
8
16
Y
Output points
Y0~Y7
Y0~Y17
8
16
X
Input points
※3
X10000~X10077(#1 expansion
module)
……
X11100~X11177(#10 expansion
module)
640
tudonghoatoancau.com

Xinje XD Series Specifications

General

Input Voltage	24V DC
Storage Temperature	-20°C to 70°C
Protection Class	IP20
Type	PLC
Series	XD
Programming Language	Ladder Logic, Instruction List
Communication Interface	RS232, RS485
Power Supply	24V DC
Digital Inputs	Available (number varies by model)
Digital Outputs	Available (number varies by model)
Analog Inputs	Available (number varies by model)
Analog Outputs	Available (number varies by model)
Output Type	Relay, Transistor
Number of Inputs	Varies by model (see Digital Inputs and Analog Inputs)
Number of Outputs	Varies by model (see Digital Outputs and Analog Outputs)
Operating Temperature	0°C to 50°C
Humidity	5% to 95% (non-condensing)
