Xinje XD Series User Manual

33
expansion BD
ID20000~ID20099(#1expansion BD)
ID20100~ID20199(#2expansion BD)
200
expansion ED
ID30000~ID30099(#1expansion ED)
100
QD
※
7
Main body
QD0~QD99
100
Expansion module
QD10000~QD10099(#1 expansion module)
……
QD11500~QD11599(#16 expansion module)
1600
expansion BD
QD20000~QD20099(#1expansion BD)
QD20100~QD20199(#2expansion BD)
200
expansion ED
QD30000~QD30099(#1expansion ED)
100
SEM
Special coil of
Sequence block
instruction WAIT
SEM0~SEM31
32
XLH series PLC soft components list:
Name
Range
Points
24 I/O
24
X
Input points
※5
X0-X13
12
Y
Output points
※5
Y0-Y13
12
X
Internal input
points
X0-X77
64
Y
Internal output
points
Y0-Y77
64
X
Module input
points
※3
X10000~X10077(#1 expansion
module)
……
X11100~X11177(#16
expansion module)
1024
Y
Module output
points
※3
Y10000~Y10077(#1 expansion
module)
……
Y11100~Y11177(#16
expansion module)
1024
X
BD input
points
※4
X20000~X20077(#1 expansion
BD)
X20100~X20177(#2 expansion
BD)
128
Y
BD output
points
※4
Y20000~Y20077(#1 expansion
BD)
Y20100~Y20177(#2 expansion
BD)
128
X
ED input
points
※5
X30000~X30077(#1 expansion
ED)
64
Y
ED output
points
※5
Y30000~Y30077(#1 expansion
ED)
64
M
Internal relay
M0~M199999
200000
HM
HM0~HM19999
※1
20000
SM
special purpose
SM0~SM49999
※2
50000
S
Flow
S0~S19999
20000
tudonghoatoancau.com

Xinje XD Series Specifications

General

Input Voltage	24V DC
Storage Temperature	-20°C to 70°C
Protection Class	IP20
Type	PLC
Series	XD
Programming Language	Ladder Logic, Instruction List
Communication Interface	RS232, RS485
Power Supply	24V DC
Digital Inputs	Available (number varies by model)
Digital Outputs	Available (number varies by model)
Analog Inputs	Available (number varies by model)
Analog Outputs	Available (number varies by model)
Output Type	Relay, Transistor
Number of Inputs	Varies by model (see Digital Inputs and Analog Inputs)
Number of Outputs	Varies by model (see Digital Outputs and Analog Outputs)
Operating Temperature	0°C to 50°C
Humidity	5% to 95% (non-condensing)
