Xinje XD Series User Manual

35
※1:
【】
Memory area is the default power outage holding area (Note: XD/XL series PLC
power outage holding area can not be modified).
※2: Special use (non-power-down maintenance) refers to registers for special use occupied
by the system, which can not be used for other purposes. For details, refer to the relevant
sections of the List of Special Soft Components in the appendix of this manual.
※3: I/O address assignment (octal) of the extended module, which can be used as
intermediate relay when the extension module is not connected. (XL1/XD1/XD2 does not
support extension modules, XD3/XL3 can expand up to 10 at the same time,
XD5/XDM/XDC/XD5E/XDME/XDH/XL5/XL5E/XLME can expand up to 16 at the same
time)
※4: Extended BD I/O address allocation (octal), can be used as intermediate relay when not
connected to BD. (24/32/30 points can be extended up to 1, 48/60 points can be extended up
to 2, 16 points do not support extended BD, XL/XDH series does not support extended BD)
※5: Extended ED I/O address allocation (octal), can be used as intermediate relay when not
connected to ED. (XD/XL series can extend up to one ED module, XDH cannot support ED
module)
※6: Analog input soft component address, can be used as auxiliary register when not
connected to extended equipment.
※7: Analog output soft component address, can be used as auxiliary registers when not
connected to extended devices.
※8: The range of soft components mentioned above is the valid range of PLC in X-NET
communication mode. In MODBUS communication mode, some relays can not read and
write. The specific usable range is shown in chapter 6-2-3.
tudonghoatoancau.com

Xinje XD Series Specifications

General

Input Voltage	24V DC
Storage Temperature	-20°C to 70°C
Protection Class	IP20
Type	PLC
Series	XD
Programming Language	Ladder Logic, Instruction List
Communication Interface	RS232, RS485
Power Supply	24V DC
Digital Inputs	Available (number varies by model)
Digital Outputs	Available (number varies by model)
Analog Inputs	Available (number varies by model)
Analog Outputs	Available (number varies by model)
Output Type	Relay, Transistor
Number of Inputs	Varies by model (see Digital Inputs and Analog Inputs)
Number of Outputs	Varies by model (see Digital Outputs and Analog Outputs)
Operating Temperature	0°C to 50°C
Humidity	5% to 95% (non-condensing)
