Xinje XD Series User Manual

434
address
Function
Note
SM099
High Speed Ring Counting enable
SM99 set ON
，
SD99 add
one per 0.1ms, cycle
between0 and 32767
Address
Function
Note
SM100
HSC0 count complete flag(100 segments)
SM101
HSC2 count complete flag(100 segments)
SM102
HSC4 count complete flag(100 segments)
SM103
HSC6 count complete flag(100 segments)
SM104
HSC8 count complete flag(100 segments)
SM105
HSC10 count complete flag(100 segments)
SM106
HSC12 count complete flag(100 segments)
SM107
HSC14 count complete flag(100 segments)
SM108
HSC16 count complete flag(100 segments)
SM109
HSC18 count complete flag(100 segments)
ID
Address
Function
Description
SM050
I0000/I0001
Forbid input interruption 0
After executing EI instruction,
the input interruption couldn’t
act independently when M
acts, even if the interruption is
allowed.
E.g.：when SM050 is
ON,I0000/I0001 is forbidden.
SM051
I0100/I0101
Forbid input interruption 1
SM052
I0200/I0201
Forbid input interruption 2
SM053
I0300/I0301
Forbid input interruption 3
SM054
I0400/I0401
Forbid input interruption 4
……
……
……
SM069
I1900/I1901
Forbid input interruption 19
SM070
I40**
Forbid timing interruption 0
After executing EI instruction,
the timing interruption
couldn’t act independently
when M acts, even if the
interruption is allowed.
SM071
I41**
Forbid timing interruption 1
SM072
I42**
Forbid timing interruption 2
SM073
I43**
Forbid timing interruption 3
SM074
I44**
Forbid timing interruption 4
……
……
……
SM089
I59**
Forbid timing interruption 19
SM090
Forbid all interruptions
Forbid all interruptions
Interruption ban(SM50-SM90)
High Speed Ring Counter(SM99)
High speed count complete(SM100-SM109)
High speed counter direction(SM110-SM119)
