Xinje XD Series User Manual

443
ID
Function
Note
SD400
SD401
Extension module no. of
communication error
Means module no.n is error
SD402
BD/ED module no. of
communication error
SD403
FROM/TO error type
SD404
PID error type
SD405
No user program
SD406
User program error type
SD407
SSDF error type
SD408
Erasure flash error type
SD409
Calculation error code
1: divide by 0 error
2: MRST, MSET front operand address less
than back operand
3: ENCO, DECO data bits of encoding and
decoding instructions exceed the limit.
4: BDC code error
7: Radical sign error
SD410
The number of offset register
D when offset crosses the
boundary
SD411
SD412
Invalid data fill value (low16
bits)
SD413
Invalid data fill value (high16
bits)
SD414
Flash register data error type
SD415
RTC real time clock error type
1: The RTC power supply has a low voltage
condition and needs to be rewritten
2: RTC writes data, and the clock chip does
not respond to the ACK signal
3: Write illegal time date data
ID
Function
Description
SD450
1：Watchdog act (Default 200ms)
2：Control block application fail
3
：
Visit illegal address
SD451
Hardware error type:
1：Register error
2：Bus error
3：Usage error
SD452
Hardware error
SD453
SD card error
SD454
Power-off time
SD455
Error Check(SD400-SD413)
Error Check(SD450-SD465)
tudonghoatoancau.com

Xinje XD Series Specifications

General

Input Voltage	24V DC
Storage Temperature	-20°C to 70°C
Protection Class	IP20
Type	PLC
Series	XD
Programming Language	Ladder Logic, Instruction List
Communication Interface	RS232, RS485
Power Supply	24V DC
Digital Inputs	Available (number varies by model)
Digital Outputs	Available (number varies by model)
Analog Inputs	Available (number varies by model)
Analog Outputs	Available (number varies by model)
Output Type	Relay, Transistor
Number of Inputs	Varies by model (see Digital Inputs and Analog Inputs)
Number of Outputs	Varies by model (see Digital Outputs and Analog Outputs)
Operating Temperature	0°C to 50°C
Humidity	5% to 95% (non-condensing)
