The counter addresses of XD/XL series PLC are in decimal; please see the following table for
details:
Series
Name
Range
Normal
Power-off
holding
High speed
counter
XD1/XD2/XD3
C
HC
HSC
C0~C575
HC0~HC95
HSC0~HSC31
XD5/XDM/XDC/XD5E/XDME
C0~C4999
HC0~HC1999
HSC0~HSC39
XDH
C0~C19999
HC0~HC1999
HSC0~HSC39
XL1/XL3
C0~C575
HC0~HC95
HSC0~HSC31
XL5/XL5E/XLME
C0~C4999
HC0~HC1999
HSC0~HSC39
XLH
C0~C19999
HC0~HC1999
HSC0~HSC39
The counter range:
Counter type
Explanation
16/32 bits up/down
counter
C0~C575 HC0~HC95 (32-bits counter occupies two registers, the
counter address must be even number)
High speed counter
HSC0~HSC30 (HSC0,HSC2...HSC30) (each counter occupies two
registers, the counter address must be even number)
1: Please refer to chapter 5 for details of high speed counter.
2: XD/XL series counters can be 16 or32 bits count up/down mode. The mode is appointed by
the instruction. Which means the same counter can be used as 16-bit or 32-bit. The
increment/subtraction counting mode is also specified by the instruction mode.
Item
16-bit counter
32-bit counter
Count direction
Count down/up
Count up/down
Set value
-32,768~32,767
-2,147,483,648~+2,147,483,647
Set value type
Constant K or register
Constant K or a couple of registers
Count value
The value will not
change when reaching
the max or min value
The value will not change when reaching
the max or min value
Output
Keep the state for count
up
Reset for count down
Reset
Run RST instruction, the counter and output will be reset
Present count
value register
16-bit
32-bit
The soft component will appoint the type of counter: common counter or power-off retentive
counter.
Counter
features
Function
