Xinje XD Series User Manual

58
to 1, 000/(20+20)=25Hz input pulse can’t be processed. But, this condition could be improved
when use PLC’s special function and applied instructions (such as high speed count, input
interruption, input filter adjustment).
 Dual output(Dual coils)action
X0
OUT Y0
Y0
OUT Y1
X1
OUT Y0
X0=ON X1=OFF
Y0=OFF Y1=ON
When executing dual output (use dual coil), the after one is act in priority.
As shown in the left map, please
consider the case of using the same coil
Y0 at many positions:
E.g.X0=ON, X1=OFF
The first Y0: X0 is ON, its image area is
ON, output Y1 is also ON.
The second Y0: as input X1 is OFF, the
image area is OFF.
So, the actual output is: Y0=OFF,
Y1= ON.
Input process
Output process
tudonghoatoancau.com

Xinje XD Series Specifications

General

Input Voltage	24V DC
Storage Temperature	-20°C to 70°C
Protection Class	IP20
Type	PLC
Series	XD
Programming Language	Ladder Logic, Instruction List
Communication Interface	RS232, RS485
Power Supply	24V DC
Digital Inputs	Available (number varies by model)
Digital Outputs	Available (number varies by model)
Analog Inputs	Available (number varies by model)
Analog Outputs	Available (number varies by model)
Output Type	Relay, Transistor
Number of Inputs	Varies by model (see Digital Inputs and Analog Inputs)
Number of Outputs	Varies by model (see Digital Outputs and Analog Outputs)
Operating Temperature	0°C to 50°C
Humidity	5% to 95% (non-condensing)
