Yamaha WaveRunner - Page 142

5-33
E
POWR
REDUCTION DRIVE GEAR
EXPLODED DIAGRAM
Step Procedure/Part name Q’ty Service points
6 Reduction drive gear case
assembly
1
7Gasket 1
8Pin 2
9 Circlip 2
10 Reduction drive gear 1
11 Washer 2
12 Drive coupling 1
Reverse the removal steps for installation.
8
8
9
11
10
11
9
7
3
2
4
12
5
4
6
E
LT
572
LT
LT
572
LT
LT
572
LT
LT
572
LT
LT
572
LT
6 × 55 mm
2nd 7.6 N • m (0.76
kgf
•
m, 5.5 ft
•
Ib)
1st 3.7 N • m (0.37
kgf
•
m, 2.7 ft
•
Ib)
28 N
•
m (2.8
kgf • m, 20 ft • Ib)
6 × 35 mm
2nd 7.6 N • m (0.76
kgf
•
m, 5.5 ft
•
Ib)
1st 3.7 N • m (0.37
kgf
•
m, 2.7 ft
•
Ib)
8 × 40 mm
2nd 28 N • m (2.8
kgf
•
m, 20 ft
•
Ib)
1st 15 N • m (1.5
kgf
•
m, 11 ft
•
Ib)
8 × 70 mm
2nd 28 N • m (2.8
kgf
•
m, 20 ft
•
Ib)
1st 15 N • m (1.5
kgf
•
m, 11 ft
•
Ib)
1
8 × 100 mm
2nd 28 N • m (2.8
kgf
•
m, 20 ft
•
Ib)
1st 15 N • m (1.5
kgf
•
m, 11 ft
•
Ib)
Not reusable
Not reusable
