Yamaha WaveRunner - Page 247

6-25
E
JET
PUMP
BEARING HOUSING
EXPLODED DIAGRAM
REMOVAL AND INSTALLATION CHART
Step Procedure/Part name Q’ty Service points
BEARING HOUSING
DISASSEMBLY
Follow the left “Step” for disassembly.
1 Grease hose 1
2 Nipple 1
3 Driven coupling 1
4 Washer 1
5 Intermediate drive shaft 1
6 O-ring 2
Not reusable
