2-15
E
SPEC
TIGHTENING TORQUES
QSTS cable end pin –
QSTS converter
Nut — 1 3.8 0.38 2.7
Shift cable locknut
(reverse gate side)
Nut — 1 2.9 0.29 2.1
572
LT
Shift cable grommet – hull Nut — 1 5.9 0.59 4.3
Shift cable holder – shift lever base Nut — 2 5.4 0.54 3.9
Steering cable locknut
(steering master side)
Nut — 1 6.4 0.64 4.6
Steering cable locknut
(jet pump side)
Nut — 1 6.5 0.65 4.7
572
LT
Steering cable grommet – hull Nut — 1 5.9 0.59 4.3
QSTS cable 1 locknut Nut — 1 16 1.6 11
QSTS cable 2 locknut Nut — 1 16 1.6 11
Steering cable bracket –
steering cable holder
Nut — 2 6.4 0.64 4.6
Steering cable bracket – deck Nut — 2 5.4 0.54 3.9
Speed sensor lead grommet – hull Nut — 1 5.9 0.59 4.3
Hinge assembly –
front hood assembly
Bolt M6 6 5.4 0.54 3.9
242
LT
Hood lock assembly –
front hood assembly
Bolt M6 2 5.4 0.54 3.9
242
LT
Hinge assembly – deck Nut — 4 5.4 0.54 3.9
Service lid 1 – deck Bolt M6 4 5.4 0.54 3.9
271
LT
Service lid 2– deck Screw M4 4 1.5 0.15 1.1
Panel – steering console cover Bolt M5 4 3.9 0.39 2.8
242
LT
Multifunction meter –
steering console cover
Bolt M5 4 3.9 0.39 2.8
242
LT
Mirror – steering console cover Nut — 4 6.9 0.69 5.0
Side cover – deck Bolt M6 8 5.4 0.54 3.9
271
LT
Steering console cover –
glove box
Bolt M6 2 5.4 0.54 3.9
242
LT
Hood lock assembly Bolt M6 2 5.4 0.54 3.9
Steering console cover – deck Nut — 2 5.4 0.54 3.9
Glove compartment – deck Nut — 2 20 2.0 14
Shift lever handle – shift lever Bolt M6 2 5.4 0.54 3.9
271
LT
Latch – glove compartment Screw M6 2 5.4 0.54 3.9
271
LT
Pilot water outlet – hull Nut — 2 4.2 0.42 3.0
Shift lever plate – deck Nut — 3 5.4 0.54 3.9
Shift lever plate –
deck/shift lever base assembly
Screw M6 3 5.4 0.54 3.9
242
LT
Shift lever – base assembly Bolt M6 1 5.4 0.54 3.9
271
LT
Shift cable ball joint –
base assembly
Nut — 1 6.8 0.68 4.9
Part to tightened Part name
Thread
size
Q’ty
Tightening torque
Remarks
N•m kgf•m ft•lb
