2-16
E
SPEC
TIGHTENING TORQUES
Hand grip – deck Nut — 4 5.2 0.52 3.8
Front seat stay – deck Nut — 2 15 1.5 11
Seat lock projection – deck beam Nut — 1 26 2.6 19
Seat lock projection – deck Nut — 1 26 2.6 19
Rear seat stay – deck beam Nut — 4 6.4 0.64 4.6
Deck beam – deck Nut — 4 18 1.8 13
Seat lock assembly – front seat Bolt M6 2 6.4 0.64 4.6
271
LT
Seat lock assembly – rear seat Bolt M6 2 6.4 0.64 4.6
271
LT
Plate/rubber hose/exhaust valve –
hull
Nut — 6 5.4 0.54 3.9
Hose clamp –
rubber hose/water lock
— — 1 3.7 0.37 2.7
Hose clamp –
rubber hose/water tank
— — 2 3.7 0.37 2.7
Joint clamp – joint/water lock — — 1 3.7 0.37 2.7
Joint clamp – joint/exhaust pipe 3 — — 1 3.7 0.37 2.7
Joint clamp – joint/exhaust joint — — 2 2.5 0.25 1.8
Sponson – hull Bolt M8 10 16 1.6 12
242
LT
Cleat – deck Nut — 2 15 1.5 11
Cleat – hull Nut — 4 15 1.5 11
Spout – hull Nut — 1 5.4 0.54 3.9
Protector (bow) – hull
Bolt M6 4 5.4 0.54 3.9
271
LT
Nut — 3 5.4 0.54 3.9
Bow eye – hull Nut — 2 13 1.3 9.4
Drain plug/packing – hull Screw M5 4 2.0 0.2 1.4
Engine mount – hull Bolt M8 8 17 1.7 12
572
LT
Engine damper – hull Bolt M6 4 6.4 0.64 4.6
271
LT
Electrical
Battery box – hull Bolt M6 2 5.4 0.54 3.9
572
LT
Battery box/spacer – hull Bolt M6 2 5.4 0.54 3.9
271
LT
Electrical box – bulk head Bolt M8 4 17 1.7 12
572
LT
Terminal cover – electrical box Screw M5 4 4.9 0.49 3.5
Cover – electrical box
Tapping
screw
ø5 18 4.9 0.49 3.5
Starter motor lead– electrical box Screw M6 1 7.6 0.76 5.5
A
Battery positive lead –
electrical box
Screw M6 1 7.6 0.76 5.5
A
Fuse holder stay – electrical box
Tapping
screw
ø6 1 3.9 0.39 2.8
ECM – electrical box
Tapping
screw
ø6 4 3.9 0.39 2.8
Part to tightened Part name
Thread
size
Q’ty
Tightening torque
Remarks
N•m kgf•m ft•lb
