Yamaha WaveRunner - Page 342

8-29
E
HULL
HOOD
STEERING CONSOLE COVER
EXPLODED DIAGRAM
REMOVAL AND INSTALLATION CHART
Step Procedure/Part name Q’ty Service points
STEERING CONSOLE COVER
AND GLOVE BOX ASSEMBLY
REMOVAL
Follow the left “Step” for removal.
1 Nut/washer 2/2
2Bolt 2
3 Nut/washer 2/2
4Bolt 2
5Bolt 2
6 Shift handle lever 1
6 × 30 mm
5.4 N • m (0.54
kgf
•
m, 3.9 ft
•
Ib)
6 × 14 mm
5.4 N • m (0.54
kgf
•
m, 3.9 ft
•
Ib)
4
9
5
6
3
1
10
12
11
7
2
6 × 18 mm
5.4 N • m (0.54
kgf
•
m, 3.9 ft
•
Ib)
6 × 22 mm
8 × 30 mm
5.4 N • m (0.54
kgf
•
m, 3.9 ft
•
Ib)
20 N • m (2.0
kgf
•
m, 14 ft
•
Ib)
8
LT
242
LT
271
LT
242
