36
E
SPEC
CABLE AND HOSE ROUTING (For FX/FX Cruiser)
Ê
A
ÈÉ
B
1
2
3
4
5
6
7
2
8
A
B
Ï
Î
Í
Ì
Ë
8
Î Fasten the ring, which is attached to the sub-
wiring harness, to the sensor bracket with a
plastic tie. Face the end of the plastic tie
towards the sensor.
Ï To bypass valve motor coupler.
