HULL
HOOD
STEERING CONSOLE COVER
STEERING CONSOLE COVER
EXPLODED DIAGRAM
REMOVAL AND INSTALLATION CHART
Step
Procedure/Part name
Q’ty Service points
METER AND METER COVER
REMOVAL
Follow the left “Step” for removal.
Handlebar assembly Refer to “HANDLEBAR”.
Service lid 1 Refer to “FRONT HOOD”.
1 Band 1
2 Multifunction meter coupler 4
3Screw 4
4 Multifunction meter cover 1
2
1
10
7
9
13
5
5
6
14
15
4
3
12
11
12
11
8
5 × 15 mm
2.2 N • m (0.22 kgf • m, 1.6 ft • Ib)
3
5 × 12 mm
3.7 N • m (0.37 kgf • m, 2.7 ft • Ib)
3
6
5
