4-3
E
FUEL
FUEL TANK AND FUEL PUMP MODULE
EXPLODED DIAGRAM
Step Procedure/Part name Q’ty Service points
4 Fuel tank breather hose 1
NOTE:
Make sure that the inner seal of the coupler
is installed properly before connecting the
coupler.
5 Fuel sender coupler 1
6 Fuel pump module coupler 1
7 Cover 1
8 Fuel hose 1
9Nut 9
10 Retainer 1
11 Fuel pump module 1
12 Packing 1
1.3 N
•
m (0.13
kgf • m, 0.9 ft • Ib)
8 × 18 mm
16 N
•
m (1.6
kgf • m, 11 ft • Ib)
5.9 N • m (0.59
kgf
•
m, 4.3 ft
•
Ib)
4.2 N • m (0.42
kgf
•
m, 3.0 ft
•
Ib)
16
17
15
3
2
2
1
7
10
9
4
5
11
8
18
19
20
21
13
12
13
LT
572
LT
572
LT
572
LT
572
2nd 6.4 N
•
m (0.64
kgf • m, 4.6 ft • Ib)
1st 3.2 N
•
m (0.32
kgf • m, 2.3 ft • Ib)
14
6
