4-13
E
FUEL
FUEL INJECTION SYSTEM
EXPLODED DIAGRAM
Step Procedure/Part name Q’ty Service points
18 Grommet 1
19 Throttle body joint 4
20 Band 2
21 Bolt 2
22 Air filter case stay 1 2
23 Band 1
24 Bolt 1
25 Air filter case stay 2 1
Reverse the removal steps for installation.
3
16
5
15
14
24
23
25
10
18
17
9
7
6
13
12
8
11
22
21
4
19
20
LT
271
LT
242
LT
271
1
2
LT
572
LT
LT
242
8 × 30 mm
2nd 18 N • m (1.8
kgf
•
m, 13 ft
•
Ib)
1st 8.8 N • m (0.88
kgf
•
m, 6.4 ft
•
Ib)
1.8 N
•
m (0.18
kgf • m, 1.3 ft • Ib)
5 × 14 mm
1.3 N
•
m (0.13
kgf • m, 0.9 ft • Ib)
5 × 14 mm
1.3 N
•
m (0.13
kgf • m, 0.9 ft • Ib)
5 × 14 mm
8 × 16 mm
2nd 39 N • m (3.9
kgf
•
m, 28 ft
•
Ib)
1st 15 N • m (1.5
kgf
•
m, 11 ft
•
Ib)
8 × 16 mm
2nd 39 N • m (3.9
kgf
•
m, 28 ft
•
Ib)
1st 15 N • m (1.5
kgf
•
m, 11 ft
•
Ib)
9
LT
572
LT
7.6 N • m (0.76
kgf
•
m, 5.5 ft
•
Ib)
6 × 16 mm
7.6 N • m (0.76
kgf
•
m, 5.5 ft
•
Ib)
6 × 16 mm
