B.3 Parameter Table
YASKAWA ELECTRIC SIEP C710616 27C YASKAWA AC Drive A1000 Technical Manual 419
Parameter List
B
F1-08
(387H)
Overspeed Detection Level
Sets the overspeed detection level as a percentage of the maximum output frequency.
Default: 115%
Min: 0%
Max: 120%
206
F1-09
(388H)
Overspeed Detection Delay Time
Sets the time in seconds for an overspeed situation to trigger a fault (oS).
Default:
<10>
Min: 0.0 s
Max: 2.0 s
206
F1-10
(389H)
Excessive Speed Deviation
Detection Level
Sets the speed deviation detection level as a percentage of the maximum output frequency.
Default: 10%
Min: 0%
Max: 50%
207
F1-11
(38AH)
Excessive Speed Deviation
Detection Delay Time
Sets the time in seconds for a speed deviation situation to trigger a fault (dEv).
Default: 0.5 s
Min: 0.0 s
Max: 10.0 s
207
F1-12
(38BH)
PG 1 Gear Teeth 1
Sets the gear ratio between the motor shaft and the encoder (PG).
A gear ratio of 1 will be used if either of these parameters is set to 0.
Default: 0
Min: 0
Max: 1000
207
F1-13
(38CH)
PG 1 Gear Teeth 2
Default: 0
Min: 0
Max: 1000
207
F1-14
(38DH)
PG Open-Circuit Detection Time
Sets the time required to trigger a PG Open fault (PGo).
Default: 2.0 s
Min: 0.0 s
Max: 10.0 s
206
F1-18
(3ADH)
dv3 Detection Selection
0: Disabled
1: Enabled
Default: 10
Min: 0
Max: 10
208
F1-19
(3AEH)
dv4 Detection Selection
0: Disabled
n: Number of pulses that the A and B pulse are reversed that triggers dv4 detection.
Default: 128
Min: 0
Max: 5000
208
F1-20
(3B4H)
PG Option Card Disconnect
Detection 1
0: Disabled
1: Enabled
Default: 1
Min: 0
Max: 1
208
F1-21
(3BCH)
PG 1 Signal Selection
0: A pulse detection
1: AB pulse detection
Default: 0
Min: 0
Max: 1
208
F1-30
(3AAH)
PG Card Option Port for Motor 2
Selection
Sets the port for the PG option card used by motor 2.
0: CN5-C
1: CN5-B
Default: 1
Min: 0
Max: 1
208
F1-31
(3B0H)
PG 2 Pulses Per Revolution
Sets the number of pulses for a PG option card connected to port CN5-B.
Default: 1024 ppr
Min: 0 ppr
Max: 60000 ppr
206
F1-32
(3B1H)
PG 2 R
ota
tion Selection
0: Pulse A leads
1: Pulse B leads
Default: 0
Min: 0
Max: 1
207
F1-33
(3B2H)
PG 2 Gear Teeth 1
Sets the gear ratio between the motor shaft and the encoder (PG).
A gear ratio of 1 will be used if either of these parameters is set to 0.
Default: 0
Min: 0
Max: 1000
207
F1-34
(3B3H)
PG 2 Gear Teeth 2
Default: 0
Min: 0
Max: 1000
207
F1-35
(3BEH)
PG 2 Division Rate for Pulse
Monitor
Sets the division ratio for the pulse monitor used of the PG option card 2 installed to connector
CN5-B. By setting “xyz”, the division ratio becomes = [(1 + x) / yz].
Default: 1
Min: 1
Max: 132
207
No.(Addr.) Name Description Setting Page
OLV/PM AOLV/PM
CLV
V/f w/PG
CLV/PM
V/f OLV
common_
TMonly
OLV/PM AOLV/PM
CLV
V/f w/PG
CLV/PM
V/f OLV
common_
TMonly
OLV/PM AOLV/PM
CLV
V/f w/PG
CLV/PM
V/f OLV
common_
TMonly
OLV/PM AOLV/PM
CLV
V/f w/PG
CLV/PM
V/f OLV
common_
TMonly
OLV/PM AOLV/PM
CLV
V/f w/PG
CLV/PM
V/f OLV
common_
TMonly
OLV/PM AOLV/PM
CLV
V/f w/PG
CLV/PM
V/f OLV
common_
TMonly
OLV/PM AOLV/PM
CLV
V/f w/PG
CLV/PM
V/f OLV
common_
TMonly
OLV/PM AOLV/PM
CLV
V/f w/PG
CLV/PM
V/f OLV
common_
TMonly
OLV/PM AOLV/PM
CLV
V/f w/PG
CLV/PM
V/f OLV
common_
TMonly
OLV/PM AOLV/PM
CLV
V/f w/PG
CLV/PM
V/f OLV
common_
TMonly
OLV/PM AOLV/PM
CLV
V/f w/PG
CLV/PM
V/f OLV
common_
TMonly
OLV/PM AOLV/PM
CLV
V/f w/PG
CLV/PM
V/f OLV
common_
TMonly
OLV/PM AOLV/PM
CLV
V/f w/PG
CLV/PM
V/f OLV
common_
TMonly
OLV/PM AOLV/PM
CLV
V/f w/PG
CLV/PM
V/f OLV
common_
TMonly
OLV/PM AOLV/PM
CLV
V/f w/PG
CLV/PM
V/f OLV
common_
TMonly
