16 Motor 2 Selection
Open: Motor 1 (E1-, E2-)
Closed: Motor 2 (E3-, E4-)
219
17 Fast Stop (N.C.)
Open: Decelerates to stop at the Fast Stop time set to C1-09.
218
18 Timer Function Input
Triggers the timer set up by parameters b4-01 and b4-02. Must be set in conjunction with the timer function output
(H2- = 12).
219
19 PID Disable
Open: PID control enabled
Closed: PID control disabled
219
1A Accel/Decel Time Selection 2
Used in conjunction with an input terminal set for “Accel/decel time selection 1” (H1- = 7), and allows the
drive to switch between accel/decel times 3 and 4.
220
1B Program Lockout
Open: Parameters cannot be edited (except for U1-01 if the reference source is assigned to the digital operator).
Closed: Parameters can be edited and saved.
220
1E Reference Sample Hold
Closed: Samples the analog frequency reference and operates the drive at that speed.
220
20 to 2F External Fault
20: N.O., Always detected, ramp to stop
21: N.C., Always detected, ramp to stop
22: N.O., During run, ramp to stop
23: N.C., During run, ramp to stop
24: N.O., Always detected, coast to stop
25: N.C., Always detected, coast to stop
26: N.O., During run, coast to stop
27: N.C., During run, coast to stop
28: N.O., Always detected, Fast Stop
29: N.C., Always detected, Fast Stop
2A: N.O., During run, Fast Stop
2B: N.C., During run, Fast Stop
2C: N.O., Always detected, alarm only (continue running)
2D: N.C., Always detected, alarm only (continue running)
2E: N.O., During run, alarm only (continue running)
2F: N.C., During run, alarm only (continue running)
220
30 PID Integral Reset
Closed: Resets the PID control integral value.
221
31 PID Integral Hold
Open: Performs integral operation.
Closed: Maintains the current PID control integral value.
221
32 Multi-Step Speed Reference 4
Used in combination with input terminals set to Multi-Step Speed Reference 1, 2, and 3. Use parameters d1-09 to
d1-16 to set reference values.
221
34 PID Soft Starter Cancel
Open: PID soft starter is enabled.
Closed: Disables the PID soft starter b5-17.
221
35 PID Input Level Selection
Closed: Inverts the PID input signal
221
40
Forward Run Command (2-wire
Sequence)
Open: Stop
Closed: Forward run
Note: Cannot be set together with settings 42 or 43.
221
41
Reverse Run Command (2-wire
Sequence)
Open: Stop
Closed: Reverse run
Note: Cannot be set together with settings 42 or 43.
221
42 Run Command (2-wire Sequence 2)
Open: Stop
Closed: Run
Note: Cannot be set together with settings 40 or 41.
221
H1 Multi-Function Digital Input Selections
H1-
Setting
Function Description Page
OLV/PM AOLV/PM
CLV
V/f w/PG
CLV/PM
V/f OLV
