■ H2: Multi-Function Digital Outputs
7A KEB Ride-Thru 2 (N.C.)
Open: KEB Ride-Thru 2 enabled. Drive disregards L2-29 and performs Single Drive KEB Ride-Thru 2.
224
7B KEB Ride-Thru 2 (N.O.)
Closed: KEB Ride-Thru 2 enabled. Drive disregards L2-29 and performs Single Drive KEB Ride-Thru 2.
224
7C Short Circuit Braking (N.O.)
Closed: Short Circuit Braking enabled
224
7D Short Circuit Braking (N.C.)
Open: Short Circuit Braking enabled
224
7E
Forward/Reverse Detection (V/f Control
with Simple PG feedback)
Direction of rotation detection (for V/f with Simple PG Feedback)
224
7F Bi-Directional PID Output Selection
Open: Bi-directional output is disabled.
Closed: Bi-directional output is enabled.
224
90 to 97 DriveWorksEZ Digital Inputs 1 to 8
Reserved for DWEZ input functions
224
9F DriveWorksEZ Disable
Open: DWEZ enabled
Closed: DWEZ disabled
224
No.(Addr.) Name Description Setting Page
H2-01
(40BH)
Terminal M1-M2 function
selection (relay)
Refer to H2 Multi-Function Digital Output Settings on page 427 for a description of setting
values.
Default: 0
Min: 0
Max: 192
224
H2-02
(40CH)
Terminal M3-M4 function
selection (relay)
Default: 1
Min: 0
Max: 192
224
H2-03
(40DH)
Terminal M5-M6 function
selection (relay)
Default: 2
Min: 0
Max: 192
224
H2-06
(437H)
Watt Hour Output Unit Selection
Outputs a 200 ms pulse signal when the watt-hour counter increases by the units selected.
0: 0.1 kWh units
1: 1 kWh units
2: 10 kWh units
3: 100 kWh units
4: 1000 kWh units
Default: 0
Min: 0
Max: 4
234
H2 Multi-Function Digital Output Settings
H2-
Setting
Function Description Page
0 During Run
Closed: A Run command is active or voltage is output.
225
1 Zero Speed
Open: Output frequency is above the minimum output frequency set in E1-09.
Closed: Output frequency is below the minimum output frequency set in E1-09.
225
2 Speed Agree 1
Closed: Output frequency equals the speed reference (plus or minus the hysteresis set to L4-02).
226
3 User-set Speed Agree 1
Closed: Output frequency and speed reference equal L4-01 (plus or minus the hysteresis set to L4-02).
226
4 Frequency Detection 1
Closed: Output frequency is less than or equal to the value in L4-01 with hysteresis determined by L4-02.
227
5 Frequency Detection 2
Closed: Output frequency is greater than or equal to the value in L4-01 with hysteresis determined by L4-02.
227
6 Drive Ready
Closed: Power up is complete and the drive is ready to accept a Run command.
227
