H3 Multi-Function Analog Input Settings
H3-
Setting
Function Description Page
0 Frequency Bias
10 V = E1-04 (maximum output frequency)
237
1 Frequency Gain
0 to 10 V signal allows a setting of 0 to 100%. -10 to 0 V signal allows a setting of -100 to 0%.
237
2
Auxiliary Frequency Reference 1 (used as a
Multi-Step Speed 2)
10 V = E1-04 (maximum output frequency)
237
3
Auxiliary Frequency Reference 2 (3rd step
analog)
10 V = E1-04 (maximum output frequency)
238
4 Output Voltage Bias
10 V = E1-05 (motor rated voltage)
238
5 Accel/Decel Time Gain
10 V = 100%
238
6 DC Injection Braking Current
10 V = Drive rated current
238
7 Overtorque/Undertorque Detection Level
10 V = Drive rated current (V/f, V/fw/PG)
10 V = Motor rated torque (OLV, CLV, OLV/PM, AOLV/PM, CLV/PM)
238
8 Stall Prevention Level During Run
10 V = Drive rated current
238
9 Output Frequency Lower Limit Level
10 V = E1-04 (maximum output frequency)
239
B PID Feedback
10 V = 100%
239
C PID Setpoint
10 V = 100%
239
D Frequency Bias
10 V = E1-04 (maximum output frequency)
239
E Motor Temperature (PTC input)
10 V = 100%
239
F Through Mode
Set this value when using the terminal in the pass-through mode.
239
10 Forward Torque Limit
10 V = Motor rated torque
239
11 Reverse Torque Limit
10 V = Motor rated torque
239
12 Regenerative Torque Limit
10 V = Motor rated torque
239
13 Torque Reference/Torque Limit
10 V = Motor rated torque
239
14 Torque Compensation
10 V = Motor rated torque
239
15 General Torque Limit
10 V = Motor rated torque
239
