B.6 Defaults by Drive Model Selection (o2-04) and ND/HD (C6-01)
458 YASKAWA ELECTRIC SIEP C710616 27C YASKAWA AC Drive A1000 Technical Manual
No. Name Unit Default Settings
Model CIMR-A – 2A0069 2A0081 2A0110 2A0138
C6-01 Drive Duty Selection –
HD ND HD ND HD ND HD ND
0 1 0 1 0 1 0 1
o2-04 Drive Model Selection Hex. 6E 6F 70 72
E2-11 (E4-11) Motor rated Output kW 15 18.5 18.5 22 22 30 30 37
b3-04 V/f Gain during Speed Search % 100 100 100 100 100 80 80 80
b3-06 Output Current 1 during Speed Search – 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5
b8-03 Energy Saving Control Filter Time Constant s 0.50 0.50 0.50 0.50 0.50 0.50 0.50 0.50
b8-04 Energy Saving Coefficient Value – 63.13 57.87 57.87 51.79 51.79 46.27 46.27 38.16
C5-17 (C5-37) Motor Inertia
kgm
2
0.076 0.138 0.138 0.165 0.165 0.220 0.220 0.273
C6-02 Carrier Frequency Selection – 1 7 1 7 1 7 1 7
E2-01 (E4-01) Motor Rated Current A 53 65.8 65.8 77.2 77.2 105 105 131
E2-02 (E4-02) Motor Rated Slip Hz 1.6 1.67 1.67 1.7 1.7 1.8 1.8 1.33
E2-03 (E4-03) Motor No-Load Current A 15.2 15.7 15.7 18.5 18.5 21.9 21.9 38.2
E2-05 (E4-05) Motor Line to Line Resistance Ω 0.138 0.101 0.101 0.079 0.079 0.064 0.064 0.039
E2-06 (E4-06) Motor Leakage Inductance % 17.2 15.7 20.1 19.5 19.5 20.8 20.8 18.8
E2-10 (E4-10) Motor Iron Loss for Torque Compensation W 272 505 505 538 538 699 699 823
E5-01 Motor Code Selection Hex. 120E 120E 120F 120F 1210 1210 1212 1212
L2-02 Momentary Power Loss Ride-Thru Time s 2 2 2 2 2 2 2 2
L2-03 Momentary Power Loss Minimum Baseblock Time s 1 1 1 1 1 1.1 1.1 1.1
L2-04 Momentary Power Loss Voltage Recovery Time s 0.6 0.6 0.6 0.6 0.6 0.6 0.6 0.6
L3-24 Motor Acceleration Time for Inertia Calculations s 0.244 0.317 0.317 0.355 0.355 0.323 0.323 0.32
L8-02 Overheat Alarm Level °C 120 120 125 125 130 130 130 130
L8-35 Installation Method Selection – 2 2 2 2 0 0 0 0
L8-38 Carrier Frequency Reduction Selection – 2 2 2 2 2 2 2 2
n1-03 Hunting Prevention Time Constant ms 10 10 10 10 10 10 10 10
n5-02 Motor Acceleration Time s 0.244 0.317 0.317 0.355 0.355 0.323 0.323 0.32
No. Name Unit Default Settings
Model CIMR-A – 2A0169 2A0211 2A0250
C6-01 Drive Duty Selection –
HD ND HD ND HD ND
0 1 0 1 0 1
o2-04 Drive Model Selection Hex. 73 74 75
E2-11 (E4-11) Motor rated Output kW 37 45 45 55 55 75
b3-04 V/f Gain during Speed Search % 80 80 80 80 80 80
b3-06 Output Current 1 during Speed Search – 0.5 0.5 0.5 0.5 0.5 0.7
b8-03 Energy Saving Control Filter Time Constant s 0.50 0.50 0.50 2.00 2.00 2.00
b8-04 Energy Saving Coefficient Value – 38.16 35.78 35.78 31.35 31.35 23.1
C5-17 (C5-37) Motor Inertia
kgm
2
0.273 0.333 0.333 0.490 0.49 0.90
C6-02Carrier Frequency Selection –171717
E2-01 (E4-01) Motor Rated Current A 131 160 160 190 190 260
E2-02 (E4-02) Motor Rated Slip Hz 1.33 1.6 1.6 1.43 1.43 1.39
E2-03 (E4-03) Motor No-Load Current A 38.2 44 44 45.6 45.6 72
E2-05 (E4-05) Motor Line to Line Resistance Ω 0.039 0.03 0.03 0.022 0.022 0.023
E2-06 (E4-06) Motor Leakage Inductance % 18.8 20.2 20.2 20.5 20.5 20
E2-10 (E4-10) Motor Iron Loss for Torque Compensation W 823 852 852 960 960 1200
E5-01 Motor Code Selection Hex. 1213 1213 1214 1214 1215 1215
L2-02Momentary Power Loss Ride-Thru Times222222
L2-03 Momentary Power Loss Minimum Baseblock Time s 1.1 1.2 1.2 1.3 1.3 1.5
L2-04Momentary Power Loss Voltage Recovery Times0.611111
L3-24 Motor Acceleration Time for Inertia Calculations s 0.32 0.387 0.387 0.317 0.317 0.533
L8-02 Overheat Alarm Level °C 130 130 125 125 115 115
L8-35Installation Method Selection –000000
L8-38Carrier Frequency Reduction Selection –222222
n1-03 Hunting Prevention Time Constant ms 10 10 10 10 10 10
n5-02 Motor Acceleration Time s 0.32 0.387 0.387 0.317 0.317 0.533
