YASKAWA A1000 Series Technical Manual

B.6 Defaults by Drive Model Selection (o2-04) and ND/HD (C6-01)
YASKAWA ELECTRIC SIEP C710616 27C YASKAWA AC Drive A1000 Technical Manual 459
Parameter List
B
Table B.9 400 V Class Drives Default Settings by Drive Capacity and ND/HD Setting
No. Name Unit Default Settings
Model CIMR-A – 2A0312 2A0360 2A0415
C6-01 Drive Duty Selection –
HD ND HD ND HD ND
0 1 0 1 0 1
o2-04 Drive Model Selection Hex. 76 77 78
E2-11 (E4-11) Motor rated Output kW 75 90 90 110 110 110
b3-04 V/f Gain during Speed Search % 80 80 80 80 80 80
b3-06 Output Current 1 during Speed Search – 0.7 0.7 0.7 0.7 0.7 0.7
b8-03 Energy Saving Control Filter Time Constant s 2.00 2.00 2.00 2.00 2.00 2.00
b8-04 Energy Saving Coefficient Value – 23.1 20.65 20.65 18.12 18.12 18.12
C5-17 (C5-37) Motor Inertia
kgm
2
0.90 1.10 1.10 1.90 1.90 1.90
C6-02Carrier Frequency Selection –171717
E2-01 (E4-01) Motor Rated Current A 260 260 260 260 260 260
E2-02 (E4-02) Motor Rated Slip Hz 1.39 1.39 1.39 1.39 1.39 1.39
E2-03 (E4-03) Motor No-Load Current A 72 72 72 72 72 72
E2-05 (E4-05) Motor Line to Line Resistance Ω 0.023 0.023 0.023 0.023 0.023 0.023
E2-06 (E4-06) Motor Leakage Inductance % 20 20 20 20 20 20
E2-10 (E4-10) Motor Iron Loss for Torque Compensation W 1200 1200 1200 1200 1200 1200
E5-01 Motor Code Selection Hex. 1216 1216 FFFF FFFF FFFF FFFF
L2-02Momentary Power Loss Ride-Thru Times222222
L2-03 Momentary Power Loss Minimum Baseblock Time s 1.5 1.5 1.5 1.7 1.7 1.7
L2-04Momentary Power Loss Voltage Recovery Times111111
L3-24 Motor Acceleration Time for Inertia Calculations s 0.533 0.592 0.592 0.646 0.646 0.646
L8-02 Overheat Alarm Level °C 120 120 120 120 120 120
L8-35 Installation Method Selection – 0 00000
L8-38Carrier Frequency Reduction Selection –222222
n1-03 Hunting Prevention Time Constant ms 10 10 100 100 100 100
n5-02 Motor Acceleration Time s 0.533 0.592 0.592 0.646 0.646 0.646
No. Name Unit Default Settings
Model CIMR-A – 4A0002 4A0004 4A0005 4A0007
C6-01 Drive Duty Selection –
HD ND HD ND HD ND HD ND
0 1 0 1 0 1 0 1
o2-04 Drive Model Selection Hex. 92 93 94 95
E2-11 (E4-11) Motor rated Output kW 0.4 0.75 0.75 1.5 1.5 2.2 2.2 3.0
b3-04 V/f Gain during Speed Search % 100 100 100 100 100 100 100 100
b3-06 Output Current 1 during Speed Search – 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5
b8-03 Energy Saving Control Filter Time Constant s 0.50 0.50 0.50 0.50 0.50 0.50 0.50 0.50
b8-04 Energy Saving Coefficient Value – 576.4 447.4 447.4 338.8 338.8 313.6 313.6 265.7
C5-17 (C5-37) Motor Inertia
kgm
2
0.0015 0.0028 0.0028 0.0068 0.0068 0.0088 0.0088 0.0158
C6-02 Carrier Frequency Selection – 1 7 1 7 1 7 1 7
E2-01 (E4-01) Motor Rated Current A 1 1.6 1.6 3.1 3.1 4.2 4.2 5.7
E2-02 (E4-02) Motor Rated Slip Hz 2.9 2.6 2.6 2.5 2.5 3 3 2.7
E2-03 (E4-03) Motor No-Load Current A 0.6 0.8 0.8 1.4 1.4 1.5 1.5 1.9
E2-05 (E4-05) Motor Line to Line Resistance Ω 38.198 22.459 22.459 10.1 10.1 6.495 6.495 4.360
E2-06 (E4-06) Motor Leakage Inductance % 18.2 14.3 14.3 18.3 18.3 18.7 18.7 19
E2-10 (E4-10) Motor Iron Loss for Torque Compensation W 14 26 26 53 53 77 77 105
E5-01 Motor Code Selection Hex. 1232 1232 1233 1233 1235 1235 1236 1236
L2-02 Momentary Power Loss Ride-Thru Time s 0.1 0.1 0.2 0.2 0.3 0.3 0.5 0.5
L2-03 Momentary Power Loss Minimum Baseblock Time s 0.2 0.3 0.3 0.4 0.4 0.5 0.5 0.5
L2-04 Momentary Power Loss Voltage Recovery Time s 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3
L3-24 Motor Acceleration Time for Inertia Calculations s 0.178 0.142 0.142 0.166 0.166 0.145 0.145 0.145
L8-02 Overheat Alarm Level °C 110 110 110 110 110 110 110 110
L8-35 Installation Method Selection – 2 2 2 2 2 2 2 2
L8-38 Carrier Frequency Reduction Selection –22222222
n1-03 Hunting Prevention Time Constant ms 10 10 10 10 10 10 10 10
n5-02 Motor Acceleration Time s 0.178 0.142 0.142 0.166 0.166 0.145 0.145 0.145

YASKAWA A1000 Series Specifications

General

Series	A1000
Type	AC Drive
Altitude	Up to 1000m without derating
Output Frequency	0-400 Hz
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Communication Options	Modbus, DeviceNet, Profibus, Ethernet/IP
Ambient Temperature	-10 to 50°C
Storage Temperature	-20 to 60°C
Humidity	5% to 95% (non-condensing)
Enclosure Rating	IP20
Horsepower	0.5 to 1000 HP
Power Range	0.4 - 630 kW (varies by voltage and model)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Cooling Method	Fan Cooled
Safety	Safe Torque Off (STO)
