YASKAWA A1000 Series Technical Manual

B.6 Defaults by Drive Model Selection (o2-04) and ND/HD (C6-01)
462 YASKAWA ELECTRIC SIEP C710616 27C YASKAWA AC Drive A1000 Technical Manual
No. Name Unit Default Settings
Model CIMR-A – 4A0362 4A0414 4A0515 4A0675
C6-01 Drive Duty Selection –
HD ND HD ND HD ND HD ND
0 1 0 1 0 1 0 1
o2-04 Drive Model Selection Hex. A9 AA AC AE
E2-11 (E4-11) Motor rated Output kW 160 185 185 220 220 250 315 355
b3-04 V/f Gain during Speed Search % 60 60 60 60 60 60 60 60
b3-06 Output Current 1 during Speed Search – 0.7 0.7 0.7 0.7 0.7 0.7 0.7 0.7
b8-03 Energy Saving Control Filter Time Constant s 2.00 2.00 2.00 2.00 2.00 2.00 2.00 2.00
b8-04 Energy Saving Coefficient Value – 30.13 30.57 30.57 27.13 27.13 21.76 21.76 23.84
C5-17 (C5-37) Motor Inertia
kgm
2
3.30 3.60 3.60 4.10 4.10 6.50 11.00 12.00
C6-02 Carrier Frequency Selection – 1 7 1 7 1 7 1 7
E2-01 (E4-01) Motor Rated Current A 270 310 310 370 370 500 500 650
E2-02 (E4-02) Motor Rated Slip Hz 1.35 1.3 1.3 1.3 1.3 1.25 1.25 1
E2-03 (E4-03) Motor No-Load Current A 70 81 81 96 96 130 130 130
E2-05 (E4-05) Motor Line to Line Resistance Ω 0.029 0.025 0.025 0.02 0.02 0.014 0.014 0.012
E2-06 (E4-06) Motor Leakage Inductance % 20 20 20 20 20 20 20 20
E2-10 (E4-10) Motor Iron Loss for Torque Compensation W 2850 3200 3200 3700 3700 4700 4700 5560
E5-01 Motor Code Selection Hex. 124A 124A FFFF FFFF FFFF FFFF FFFF FFFF
L2-02 Momentary Power Loss Ride-Thru Time s 2 2 2 2 2 2 2 2
L2-03 Momentary Power Loss Minimum Baseblock Time s 1.8 1.9 1.9 2 2 2.1 2.1 2.3
L2-04 Momentary Power Loss Voltage Recovery Time s 1 1 1 1 1 1 1 1
L3-24 Motor Acceleration Time for Inertia Calculations s 0.777 0.864 0.864 0.91 0.91 1.392 1.392 1.667
L8-02 Overheat Alarm Level °C 130 130 140 140 140 140 140 140
L8-35 Installation Method Selection – 0 0 0 0 0 0 0 0
L8-38 Carrier Frequency Reduction Selection – 2 2 2 2 2 2 2 2
n1-03 Hunting Prevention Time Constant ms 30 30 100 100 100 100 100 100
n5-02 Motor Acceleration Time s 0.777 0.864 0.864 0.91 0.91 1.392 1.392 1.667

YASKAWA A1000 Series Specifications

General

Series	A1000
Type	AC Drive
Altitude	Up to 1000m without derating
Output Frequency	0-400 Hz
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Communication Options	Modbus, DeviceNet, Profibus, Ethernet/IP
Ambient Temperature	-10 to 50°C
Storage Temperature	-20 to 60°C
Humidity	5% to 95% (non-condensing)
Enclosure Rating	IP20
Horsepower	0.5 to 1000 HP
Power Range	0.4 - 630 kW (varies by voltage and model)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Cooling Method	Fan Cooled
Safety	Safe Torque Off (STO)
