C.9 MEMOBUS/Modbus Data Table
YASKAWA ELECTRIC SIEP C710616 27C YASKAWA AC Drive A1000 Technical Manual 499
MEMOBUS/Modbus
Communications
C
00E0H
oFb3x Contents (CN5-B)
bit 0 Comm. ID Error (oFb30)
bit 1 Model Code Error (oFb31)
bit 2 Sumcheck Error (oFb32)
bit 3 Comm. option timeout waiting for response (oFb33)
bit 4 MEMOBUS Timeout (oFb34)
bit 5 Drive timeout waiting for response (oFb35)
bit 6 CI Check Error (oFb36)
bit 7 Drive timeout waiting for response (oFb37)
bit 8 Control Command Selection Error (oFb38)
bit 9 Drive timeout waiting for response (oFb39)
bit A Control Response Selection 1 Error (oFb40)
bit B Drive timeout waiting for response (oFb41)
bit C Control Response Selection 2 Error (oFb42)
bit D Control Response Selection Error (oFb43)
bit E, F Reserved
00E1H
oFC0x Contents (CN5-C)
bit 0 Option compatibility error (oFC00)
bit 1 Option not properly connected (oFC01)
bit 2 Same type of option card already connected (oFC02)
bit 3, 4 Reserved
bit 5 A/D Conversion Fault (oFC05)
bit 6 Option Response Error (oFC06)
bit 7 to F Reserved
00E2H
oFC1x Contents (CN5-C)
bit 0 Option RAM Fault (oFC10)
bit 1 Option Operation Mode Fault (SLMOD) (oFC11)
bit 2 Drive Receive CRC Error (oFC12)
bit 3 Drive Receive Frame Error (oFC13)
bit 4 Drive Receive Abort Error (oFC14)
bit 5 Option Receive CRC Error (oFC15)
bit 6 Option Receive Frame Error (oFC16)
bit 7 Option Receive Abort Error (oFC17)
bit 8 to F Reserved
00E3H, 00E4H Reserved
00E5H
oFC3x Contents (CN5-C)
bit 0 Comm. ID Error (oFC30)
bit 1 Model Code Error (oFC31)
bit 2 Sumcheck Error (oFC32)
bit 3 Comm. option timeout waiting for response (oFC33)
bit 4 MEMOBUS Timeout (oFC34)
bit 5 Drive timeout waiting for response (oFC35)
bit 6 CI Check Error (oFC36)
bit 7 Drive timeout waiting for response (oFC37)
bit 8 Control Command Selection Error (oFC38)
bit 9 Drive timeout waiting for response (oFC39)
bit A Control Response Selection 1 Error (oFC40)
bit B Drive timeout waiting for response (oFC41)
bit C Control Response Selection 2 Error (oFC42)
bit D Control Response Selection Error (oFC43)
bit E, F Reserved
00E6H to 00FFH Reserved
<1> Units are determined by parameter o1-03.
<2> This value's number of decimal places depends on the drive model and the Heavy/Normal duty selection in parameter C6-01. The value will
have two decimal places (0.01 A) if the drive is set for a Maximum Applicable Motor Capacity up to 11 kW (refer to Table A.2 and Table A.3)
and one decimal place (0.1 A) if the set Maximum Applicable Motor Capacity is higher than 11 kW.
<3> The contents of a communication error are saved until the fault is reset.
<4> Depending on the motor used, the correct motor pole number must be set to parameter E2-04, E4-04, or E5-05.
Register No. Contents
