C.9 MEMOBUS/Modbus Data Table
498 YASKAWA ELECTRIC SIEP C710616 27C YASKAWA AC Drive A1000 Technical Manual
00D8H
oFA0x Contents (CN5-A)
bit 0 Option Compatibility Error (oFA00)
bit 1 Option not properly connected (oFA01)
bit 2 Same type of option card already connected (oFA02)
bit 3, 4 Reserved
bit 5 A/D Conversion Error (oFA05)
bit 6 Option Response Error (oFA06)
bit 7 to F Reserved
00D9H
oFA1x Contents (CN5-A)
bit 0 Option RAM Fault (oFA10)
bit 1 Option Operation Mode Fault (SLMOD) (oFA11)
bit 2 Drive Receive CRC Error (oFA12)
bit 3 Drive Receive Frame Error (oFA13)
bit 4 Drive Receive Abort Error (oFA14)
bit 5 Option Receive CRC Error (oFA15)
bit 6 Option Receive Frame Error (oFA16)
bit 7 Option Receive Abort Error (oFA17)
bit 8 to F Reserved
00DAH to 00DBH Reserved
00DBH
oFA3x Contents (CN5-A)
bit 0 Comm. ID Error (oFA30)
bit 1 Model Code Error (oFA31)
bit 2 Sumcheck Error (oFA32)
bit 3 Comm. option timeout waiting for response (oFA33)
bit 4 MEMOBUS Timeout (oFA34)
bit 5 Drive timeout waiting for response (oFA35)
bit 6 CI Check Error (oFA36)
bit 7 Drive timeout waiting for response (oFA37)
bit 8 Control Command Selection Error (oFA38)
bit 9 Drive timeout waiting for response (oFA39)
bit A Control Response Selection 1 Error (oFA40)
bit B Drive timeout waiting for response (oFA41)
bit C Control Response Selection 2 Error (oFA42)
bit D Control Response Selection Error (oFA43)
bit E, F Reserved
00DCH
oFb0x Contents (CN5-B)
bit 0 Option compatibility error (oFb00)
bit 1 Option not properly connected (oFb01)
bit 2 Same type of option card already connected (oFb02)
bit 3, 4 Reserved
bit 5 A/D Conversion Fault (oFb05)
bit 6 Option Response Error (oFb06)
bit 7 to F Reserved
00DDH
oFb1x Contents (CN5-B)
bit 0 Option RAM Fault (oFb10)
bit 1 Option Operation Mode Fault (SLMOD) (oFb11)
bit 2 Drive Receive CRC Error (oFb12)
bit 3 Drive Receive Frame Error (oFb13)
bit 4 Drive Receive Abort Error (oFb14)
bit 5 Option Receive CRC Error (oFb15)
bit 6 Option Receive Frame Error (oFb16)
bit 7 Option Receive Abort Error (oFb17)
bit 8 to F Reserved
00DEH to 00DFH Reserved
Register No. Contents

YASKAWA A1000 Series Specifications

General

Series	A1000
Type	AC Drive
Altitude	Up to 1000m without derating
Output Frequency	0-400 Hz
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Communication Options	Modbus, DeviceNet, Profibus, Ethernet/IP
Ambient Temperature	-10 to 50°C
Storage Temperature	-20 to 60°C
Humidity	5% to 95% (non-condensing)
Enclosure Rating	IP20
Horsepower	0.5 to 1000 HP
Power Range	0.4 - 630 kW (varies by voltage and model)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Cooling Method	Fan Cooled
Safety	Safe Torque Off (STO)
