YASKAWA A1000 Series Technical Manual

D.2 European Standards
YASKAWA ELECTRIC SIEP C710616 27C YASKAWA AC Drive A1000 Technical Manual 513
Standards Compliance
D
■ EMC Filters
The drive should be installed with the EMC filters listed below in order to comply with the EN61800-3 requirements.
Note: If the Safe Disable function of the drive is part of the safety concept of a machine or installation and used for a safe stop
according to EN60204-1, stop category 0, use only filters manufactured by Schaffner as listed below.
Table D.1 EN61800-3 Filters
Model
CIMR-A
Filter Data (Manufacturer: Schaffner)
Type Rated Current (A)
Weight
(kg)
Dimensions
[W x D x H]
(mm)
Y x X Figure
Three-Phase 200 V Class
2A0004
FS5972-10-07 10 1.2 141 × 46 × 330 115 × 313
1
2A0006
2A0010
FS5972-18-07 18 1.3 141 × 46 × 330 115 × 313
2A0012
2A0021
FS5972-35-07 35 2.1 206 × 50 × 355 175 × 336
2A0030
2A0040
FS5972-60-07 60 4.0 236 × 65 × 408 205 × 390
2A0056
2A0069
FS5972-100-35 100 3.4 90 × 150 × 330 65 × 255
2
2A0081
2A0110
FS5972-170-40 170 6.0 120 × 170 × 451 102 × 365
2A0138
2A0169
FS5972-250-37 250 11.7 130 × 240 × 610 90 × 498
2A0211
2A0250
FS5972-410-99 410 10.5 260 × 115 × 386 235 × 120
3
2A0312
2A0360
FS5972-600-99 600 11 260 × 135 × 386 235 × 120
2A0415
Three-Phase 400 V Class
4A0002
FS5972-10-07 10 1.1 141 × 46 × 330 115 × 313
1
4A0004
4A0005
4A0007
4A0009
FS5972-18-07 18 1.7 141 × 46 × 330 115 × 313
4A0011
4A0018
FS5972-35-07 35 2.1 206 × 50 × 355 175 × 336
4A0023
4A0031
4A0038
FS5972-60-07 60 4 236 × 65 × 408 202 × 390
4A0044
4A0058
4A0072
FS5972-100-35 100 3.4 90 × 150 × 330 65 × 255
2
4A0088
4A0103
FS5972-170-35 170 4.7 120 × 170 × 451 102 × 365
4A0139
4A0165
4A0208 FS5972-250-37 250 11.7 130 × 240 × 610 90 × 498
4A0250
FS5972-410-99 400 10.5 260 × 115× 386 235 × 120
3
4A0296
4A0362
4A0414
FS5972-600-99 600 11 260 × 135× 386 235 × 120
4A0515
4A0675 FS5972-800-99 800 31.5 300 × 160 × 716 275 × 210

YASKAWA A1000 Series Specifications

General

Series	A1000
Type	AC Drive
Altitude	Up to 1000m without derating
Output Frequency	0-400 Hz
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Communication Options	Modbus, DeviceNet, Profibus, Ethernet/IP
Ambient Temperature	-10 to 50°C
Storage Temperature	-20 to 60°C
Humidity	5% to 95% (non-condensing)
Enclosure Rating	IP20
Horsepower	0.5 to 1000 HP
Power Range	0.4 - 630 kW (varies by voltage and model)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Cooling Method	Fan Cooled
Safety	Safe Torque Off (STO)
