YASKAWA A1000 Series

D.2 European Standards
514 YASKAWA ELECTRIC SIEP C710616 27C YASKAWA AC Drive A1000 Technical Manual
Figure D.5
Figure D.5 EMC Filter Dimensions
■ DC Reactors for EN 61000-3-2 Compliance
Table D.2 DC Reactors for Harmonics Reduction
Note: Contact Yaskawa for information about DC reactors for other models.
Drive Model
CIMR-A
DC Reactor
Model Rating
200V Three-Phase Units
2A0004
UZDA-B
5.4 A
8 mH
2A0006
400 V Three-Phase Units
4A0002
UZDA-B
3.2 A
28 mH
4A0004
H X
D
X H
W
DY
W
Y
Figure 1
Figure 3
Figure 2
W
Y
XX
H
D
YEG
