YASKAWA A1000 Series Technical Manual

E.3 User Setting Table
526 YASKAWA ELECTRIC SIEP C710616 27C YASKAWA AC Drive A1000 Technical Manual
E5-02 Motor Rated Power
E5-03 Motor Rated Current
E5-04 Number of Motor Poles
E5-05 Motor Stator Resistance
E5-06 Motor d-Axis Inductance
E5-07 Motor q-Axis Inductance
E5-09 Motor Induction Voltage Constant 1
E5-11 Encoder Z-pulse Offset
E5-24 Motor Induction Voltage Constant 2
F1-01 PG 1 Pulses Per Revolution
F1-02 Operation Selection at PG Open Circuit (PGo)
F1-03 Operation Selection at Overspeed (oS)
F1-04 Operation Selection at Deviation
F1-05 PG 1 Rotation Selection
F1-06 PG 1 Division Rate for PG Pulse Monitor
F1-08 Overspeed Detection Level
F1-09 Overspeed Detection Delay Time
F1-10 Excessive Speed Deviation Detection Level
F1-11 Excessive Speed Deviation Detection Delay Time
F1-12 PG 1 Gear Teeth 1
F1-13 PG 1 Gear Teeth 2
F1-14 PG Open-Circuit Detection Time
F1-18 dv3 Detection Selection
F1-19 dv4 Detection Selection
F1-20 PG Option Card Disconnect Detection 1
F1-21 PG 1 Signal Selection
F1-30 PG Option Card Port for Motor 2 Selection
F1-31 PG 2 Pulses Per Revolution
F1-32 PG 2 Rotation Selection
F1-33 PG 2 Gear Teeth 1
F1-34 PG 2 Gear Teeth 2
F1-35 PG 2 Division Rate for PG Pulse Monitor
F1-36 PG Option Card Disconnect Detection 2
F1-37 PG2 Signal Selection
F2-01 Analog Input Option Card Operation Selection
F2-02 Analog Input Option Card Gain
F2-03 Analog Input Option Card Bias
F3-01 Digital Input Option Card Input Selection
F3-03 Digital Input Option DI-A3 Data Length Selection
F4-01 Terminal V1 Monitor Selection
F4-02 Terminal V1 Monitor Gain
F4-03 Terminal V2 Monitor Selection
F4-04 Terminal V2 Monitor Gain
F4-05 Terminal V1 Monitor Bias
F4-06 Terminal V2 Monitor Bias
F4-07 Terminal V1 Signal Level
F4-08 Terminal V2 Signal Level
F5-01 Terminal P1-PC Output Selection
F5-02 Terminal P2-PC Output Selection
F5-03 Terminal P3-PC Output Selection
F5-04 Terminal P4-PC Output Selection
F5-05 Terminal P5-PC Output Selection
F5-06 Terminal P6-PC Output Selection
F5-07 Terminal M1-M2 Output Selection
F5-08 Terminal M3-M4 Output Selection
F5-09 DO-A3 Output Mode Selection
F6-01 Communications Error Operation Selection
F6-02 External Fault from Comm. Option Detection Selection
F6-03 External Fault from Comm. Option Operation Selection
F6-04 bUS Error Detection Time
F6-06
Torque Reference/Torque Limit Selection from Comm.
Option
F6-07
Multi-Step Speed Enable/Disable Selection when NetRef/
ComRef is Selected
F6-08 Reset Communication Parameters
F6-10 CC-Link Node Address
No. Name
User
Setting
F6-11 CC-Link Communications Speed
F6-14 CC-Link bUS Error Auto Reset
F6-20 MECHATROLINK Station Address
F6-21 MECHATROLINK Frame Size
F6-22 MECHATROLINK Link Speed
F6-23 MECHATROLINK Monitor Selection (E)
F6-24 MECHATROLINK Monitor Selection (F)
F6-25 Operation Selection at Watchdog Timer Error (E5)
F6-26 MECHATROLINK bUS Errors Detected
F6-30 PROFIBUS-DP Node Address
F6-31 PROFIBUS-DP Clear Mode Selection
F6-32 PROFIBUS-DP Data Format Selection
F6-35 CANopen Node ID Selection
F6-36 CANopen Communication Speed
F6-50 DeviceNet MAC Address
F6-51 DeviceNet Communication Speed
F6-52 DeviceNet PCA Setting
F6-53 DeviceNet PPA Setting
F6-54 DeviceNet Idle Mode Fault Detection
F6-55 DeviceNet Baud Rate Monitor
F6-56 DeviceNet Speed Scaling
F6-57 DeviceNet Current Scaling
F6-58 DeviceNet Torque Scaling
F6-59 DeviceNet Power Scaling
F6-60 DeviceNet Voltage Scaling
F6-61 DeviceNet Time Scaling
F6-62 DeviceNet Heartbeat Interval
F6-63 DeviceNet Network MAC ID
H1-01
Multi-Function Digital Input Terminal S1 Function
Selection
H1-02
Multi-Function Digital Input Terminal S2 Function
Selection
H1-03
Multi-Function Digital Input Terminal S3 Function
Selection
H1-04
Multi-Function Digital Input Terminal S4 Function
Selection
H1-05
Multi-Function Digital Input Terminal S5 Function
Selection
H1-06
Multi-Function Digital Input Terminal S6 Function
Selection
H1-07
Multi-Function Digital Input Terminal S7 Function
Selection
H1-08
Multi-Function Digital Input Terminal S8 Function
Selection
H2-01 Terminal M1-M2 Function Selection (relay)
H2-02 Terminal M3-M4 Function Selection
H2-03 Terminal M5-M6 Function Selection
H2-06 Watt Hour Output Unit Selection
H3-01 Terminal A1 Signal Level Selection
H3-02 Terminal A1 Function Selection
H3-03 Terminal A1 Gain Setting
H3-04 Terminal A1 Bias Setting
H3-05 Terminal A3 Signal Level Selection
H3-06 Terminal A3 Function Selection
H3-07 Terminal A3 Gain Setting
H3-08 Terminal A3 Bias Setting
H3-09 Terminal A2 Signal Level Selection
H3-10 Terminal A2 Function Selection
H3-11 Terminal A2 Gain Setting
H3-12 Terminal A2 Bias Setting
H3-13 Analog Input Filter Time Constant
H3-14 Analog Input Terminal Enable Selection
H4-01
Multi-Function Analog Output Terminal FM Monitor
Selection
H4-02 Multi-Function Analog Output Terminal FM Gain
H4-03 Multi-Function Analog Output Terminal FM Bias
H4-04
Multi-Function Analog Output Terminal AM Monitor
Selection
No. Name
User
Setting

YASKAWA A1000 Series Specifications

General

Series	A1000
Type	AC Drive
Altitude	Up to 1000m without derating
Output Frequency	0-400 Hz
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Communication Options	Modbus, DeviceNet, Profibus, Ethernet/IP
Ambient Temperature	-10 to 50°C
Storage Temperature	-20 to 60°C
Humidity	5% to 95% (non-condensing)
Enclosure Rating	IP20
Horsepower	0.5 to 1000 HP
Power Range	0.4 - 630 kW (varies by voltage and model)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Cooling Method	Fan Cooled
Safety	Safe Torque Off (STO)
