2 Security System

DX100 2.1 Protection Through Security Mode Settings

2-2

Table 2-2: Menu & Security Mode (Sheet 1 of 4)

Main Menu Sub Menu Allowed Security Mode

DISPLAY EDIT

JOB JOB Operation Edit

SELECT JOB Operation Operation

CREATE NEW JOB

Edit Edit

MASTER JOB Operation Edit

JOB CAPACITY Operation -

RES. START (JOB)

Edit Edit

RES. STATUS

Operation -

CYCLE Operation Operation

VARIABLE BYTE Operation Edit

INTEGER Operation Edit

DOUBLE Operation Edit

REAL Operation Edit

STRING Operation Edit

POSITION (ROBOT) Operation Edit

POSITION (BASE) Operation Edit

POSITION (ST) Operation Edit

LOCAL VARIABLE Operation -

IN/OUT EXTERNAL INPUT Operation -

EXTERNAL OUTPUT Operation -

UNIVERSAL INPUT Operation -

UNIVERSAL OUTPUT Operation -

SPECIFIC INPUT Edit -

SPECIFIC OUTPUT Edit -

RIN Edit -

CPRIN Operation -

AUXILIARY RELAY Edit -

CONTROL INPUT Edit -

PSEUDO INPUT SIG Edit Management

NETWORK INPUT Edit -

NETWORK OUTPUT Operation -

ANALOG OUTPUT Edit -

SV POWER STATUS Edit -

LADDER PROGRAM Management Management

I/O ALARM Management Management

I/O MESSAGE Management Management
