5 Replacing Parts
DX100 5.4 Recommended Spare Parts
5-31
Table 5-5: Recommended Spare Parts List of DX100 for VA1400
Rank Parts
No.
Name Type Manufacturer Qty Qty
per
Unit
Remarks
A 1 Battery ER6VC3N 3.6V TOSHIBA
BATTERY CO.,
LTD.
11
A 2 CPS Unit
Cooling Fan
JZNC-YZU01-E Yaskawa Electric
Corporation
22
A 3 Interior
Circulation Fan
4715MS-22T-B50-B00 Minebea Co., Ltd 1 1
A 4 Backside Duct
Fan
4715MS-22T-B50-B00 Minebea Co., Ltd 2 2
A 5 AC Control
Power supply
Fuse
0218010P LITTEL 2 2
A6 Brake Fuse for
AC Cooling Fan
GP25 2.5A 250V Daito
Communication
Apparatus Co.,
Ltd.
22
A 7 24VDC Fuse for
I/O
Brake Power
Supply Fuse for
External Axis
02173.15P 3.15A 250V LITTEL 3 5
C 8 Converter SRDA-COA12A01A-E Yaskawa Electric
Corporation
1 1 SERVOPAC?
JZRCR-MH6-
14/00
B 9 Servo Amplifier
1, 2, 3, 7
SRDA-SDA14A01A-E Yaskawa Electric
Corporation
34
B 10 Servo Amplifier
4,5,6
SRDA-SDA06A01A-E Yaskawa Electric
Corporation
33
B11Basic Axis
Control Circuit
Board
SRDA-EAXA01A Yaskawa Electric
Corporation
11
B 12 External Axis
Control Circuit
Board
SRDA-EAXB01A Yaskawa Electric
Corporation
11
C 13 CPU Unit JZNC-YRK01-1E Yaskawa Electric
Corporation
11
1)
B 14 Robot I/F circuit
board
JANCD-YIF01-1E Yaskawa Electric
Corporation
11
C 15 Power Supply
Contactor Unit
JZRCR-YPU01-1 Yaskawa Electric
Corporation
11
B 16 Power Supply
Contactor Board
JARCR-YPC01-1 Yaskawa Electric
Corporation
11
C 17 CPS Unit JZNC-YPS01-E Yaskawa Electric
Corporation
11
B 18 Brake board JANCD-YBK01-1E Yaskawa Electric
Corporation
11
C 19 Machine Safety
Unit
JANC-YSU01-1E Yaskawa Electric
Corporation
11
C 20 I/O Unit JZNC-YIU01-E Yaskawa Electric
Corporation
11
C 21 Programming
Pendant
JZRCR-YPP01-1 Yaskawa Electric
Corporation
1 1 With Cable (8M)
1
The CPU unit (JZNC-YRK01-1E) does not include the Robot I/F
Unit (JANCD-YIF01-1E). Must be ordered separately if required.
