8.8 Manual T
uning
8.8.3 Mo
de Switching (Chan
ging be
tween Proportional and PI Control)
8-43
8
T
uning
Using the Position Deviation as
the Mode Switching Condition
When the position deviation equals
or exceeds
the value set for the m
ode switching level for
position deviation (Pn10F), the speed loop is changed to
P control.
Pn10F
PI
Speed
Speed refer
ence
Motor speed
Tim
e
P control
PI control
Position deviation
218
