10.1 Alarm and Warning Displays
10.1.9 Alarm History Clear
10-19
2.
Click the Alarm History Ta b.
The following display will appear and you can check the alarms that occurred in the past.
10.1.9
Alarm History Clear
You can clear the alarm history that is recorded in the SERVOPACK.
The alarm history is not cleared when alarms are reset or when the SERVOPACK power supply
is turned OFF. You must perform the following procedure.
Preparations
Check the following setting before you clear the alarm history.
• The parameters must not be write prohibited.
Operating Procedure
Use the following procedure.
1.
Select Alarm - Display Alarm from the menu bar of the Main Window of the Sig-
maWin+.
The Alarm Display Dialog Box will be displayed.
2.
Click the Alarm History Ta b.
3.
Click the Clear Button.
The alarm history will be cleared.
1. If the same alarm occurs consecutively within one hour, it is not saved in the alarm history.
If it occurs after an hour or more, it is saved.
2. You can clear the alarm history by clicking the Clear Button. The alarm history is not
cleared when you reset alarms or turn OFF the power supply to the SERVOPACK.
3. Warnings are not recorded in the alarm history.
Alarm number: Alarm name
Alarms in order of occurrence
(Older alarms have higher values.)
Accumulated operation time
Total operation time to the point at which the alarm occurred
is displayed in increments of 100 ms from when the control
power supply and main circuit power supply turned ON.
For 24-hour, 365-day operation, measurements are possible for
approximately 13 years.
To Next Page
