8.7 Vibration Suppression
8.7.2 Preparations
8-29
8.7.2
Preparations
Check the following settings before you execute vibration suppression.
• The parameters must not be write prohibited.
8.7.3
Operating Procedure
Use the following procedure to perform vibration suppression.
1.
Perform steps 1 to 7 of the procedure for custom tuning. Refer to the following section
for details.
8.5.3 Operating Procedure on page 8-16
2.
Click the Vib Suppress Button.
3.
Click the Import Button or click and Button to manually adjust the set frequency.
When you click the Import Button, the residual vibration frequency in the motor is read as the set fre-
quency. (The frequency can be read only when the residual vibration frequency is between 1.0 and
100.0.)
Frequency detection will not be performed if there is no vibration or if the vibration frequency
is outside the range of detectable frequencies. If a vibration frequency is not detected, pro-
vide a means of measuring the vibration frequency.
To Next Page
