5.1 Manipulating Parameters (Pn)
5.1.2 Notation for Parameters
5-4
5.1.2
Notation for Parameters
There are two types of notation used for parameters that depend on whether the parameter
requires a numeric setting (parameter for numeric setting) or requires the selection of a function
(parameter for selecting a function).
•
Parameters for Numeric Settings
Parameter Meaning When Enabled Classification
Pn140
n.
0
(default setting)
Do not perform vibration suppression.
Immediately Tuning
n.
1
Perform vibration suppression for a specific frequency.
n.
2
Reserved setting (Do not use.)
This column explains
the functions selected
with the settings.
The notation “n.
” indicates a parameter for
selecting functions.
Each
indicates the setting for one digit.
The notation shown here means that the third digit
from the right is set to 2.
Pn100
Speed Loop Gain
Setting Range
10 to 20,000 0.1 Hz 400 Immediately
Setting Unit Default Setting When Enabled
Classification
Tuning
This is the setting range
for the parameter.
Parameter
number
This is the
parameter setting
before shipment.
This is when any
change made to the
parameter will
become effective.
This is the parameter
classification.
This is the minimum
unit (setting increment)
that you can set for
the parameter.
Parameter
number
•
