2.5 Selecting Cables

2.5.7 Computer Cable

2-19

Selection

2.5.7

Computer Cable

Selection Table

Dimensional Drawing

Wiring Specifications

31 SO13 E-STPS Orange Red 

32 - - Orange Black 

Pin Signal Default Signals

Wire

Color

Markings

Color Number

Use the Yaskawa-specified cable for the Computer Cable. Operation may not be dependable

with any other cable.

Order Number Length (L)

JZSP-CPS00-02-E 2 m

Important

SERVOPACK end

D-sub 9-pin

connector

Computer end

SERVOPACK end Computer end (D-sub 9-pin)

Signal Pin Pin Signal

TXD 1 2 RXD

RXD 2 3 TXD

GND 3 5 GND

GND 4 7 RTS

8 CTS

Case FG

Shield
