7 - 14 DS457-XX20004ZZWW Fixed Mount Imager Integration Guide
Snapshot Mode Timeout
Parameter # 323 (SSI # F0h 43h)
This parameter sets the amount of time the imager remains in Snapshot Mode. The imager exits Snapshot
Mode upon a trigger event, or when the Snapshot Mode Timeout elapses. To set this timeout value, scan the
bar code below followed by a bar code from Appendix G, Numeric Bar Codes. The default value is 0 which
represents 30 seconds; values increment by 30. For example, 1 = 60 seconds, 2 = 90 seconds, etc.
Snapshot Aiming Pattern
Parameter # 300 (SSI # F0h 2Ch)
Select Enable Snapshot Aiming Pattern to project the aiming pattern when in Snapshot Mode, or Disable
Snapshot Aiming Pattern to turn the aiming pattern off.
Snapshot Mode Timeout
*Enable Snapshot Aiming Pattern
(1)
Disable Snapshot Aiming Pattern
(0)
