Zebra DS457 Series - Beeper Tone

To Next Page

To Previous Page

User Preferences 6 - 9

Beeper Tone

Parameter # 145 (SSI # 91h)

To select a decode beep frequency (tone), scan the Low Frequency, Medium Frequency, or High

Frequency bar code.

Low Frequency

(2)

*Medium Frequency

(Optimum Setting)

(1)

High Frequency

(0)
