ABOUT THIS GUIDE
Introduction
The DS457-XX20004ZZWW Fixed Mount Imager Integration Guide provides general instructions for mounting,
setting up, and programming the DS457 fixed mount imager.
Configurations
The DS457-XX20004ZZWW offers the following configurations:
•
DS457-SR - Standard range imager
•
DS457-HD - High density imager
•
DS457-DP - High density imager with Direct Part Marking (DPM) software
•
DS457-DL - Standard range imager, driver’s license parsing
Chapter Descriptions
Topics covered in this guide are as follows:
•
Chapter 1, Getting Started provides an overview of the DS457 imager, including applications and a theory of
operation.
•
Chapter 2, Installation provides mounting and connection information for the DS457, and lists accessories.
•
Chapter 3, Imaging provides information on the aiming and illumination system, and includes imaging tips
and a list of supported symbologies.
•
Chapter 4, Specifications provides technical specifications including electrical and mechanical information,
and provides decode ranges.
•
Chapter 5, Maintenance & Troubleshooting provides maintenance and troubleshooting tips.
•
Chapter 6, User Preferences provides programming bar codes for selecting user preference features.
•
Chapter 7, Imager Preferences provides programming bar codes for selecting imager preference features.
