12 - 2 DS457-XX20004ZZWW Fixed Mount Imager Integration Guide
Scanning Sequence Examples
In most cases, scanning one bar code sets the parameter value. For example, to transmit bar code data
without the UPC-A check digit, simply scan the Do Not Transmit UPC-A Check Digit bar code under Transmit
UPC-A Check Digit on page 12-19. The imager issues a fast warble beep and the LED turns green, signifying
a successful parameter entry.
Other parameters, such as Set Length(s) for D 2 of 5 require scanning several bar codes. See the individual
parameter, such as Set Length(s) for D 2 of 5, for this procedure.
Errors While Scanning
Unless otherwise specified, to correct an error during a scanning sequence, just re-scan the correct parameter.
Symbology Parameter Defaults
Table 12-1 lists the defaults for all symbologies parameters. To change any option, scan the appropriate bar
code(s) provided in the Symbologies Parameters section beginning on page 12-10.
NOTE See Appendix A, Standard Default Parameters for all user preferences, hosts, and miscellaneous default
parameters.
Table 12-1
Symbology Default Table
Parameter
Parameter
Number
SSI
Number
Default
Page
Number
Enable/Disable All Code Types
N/A N/A N/A
12-9
UPC/EAN
UPC-A 1 01h Enable
12-10
UPC-E 2 02h Enable
12-10
UPC-E1 12 0Ch Disable
12-11
EAN-8/JAN 8 4 04h Enable
12-11
EAN-13/JAN 13 3 03h Enable
12-12
Bookland EAN 83 53h Disable
12-12
Decode UPC/EAN/JAN Supplementals
(2 and 5 digits)
16 10h Ignore
12-13
User-Programmable Supplementals
Supplemental 1:
Supplemental 2:
579
580
F1h 43h
F1h 44h
12-16
UPC/EAN/JAN Supplemental Redundancy 80 50h 10
12-16
UPC/EAN/JAN Supplemental AIM ID Format 672 F1h A0h Combined
12-17
