Symbologies 12 - 53
I 2 of 5 Security Level
Parameter # 1121
Interleaved 2 of 5 bar codes are vulnerable to misdecodes, particularly when I 2 of 5 Lengths is set to Any
Length. The imager offers four levels of decode security for Interleaved 2 of 5 bar codes. There is an inverse
relationship between security and imager aggressiveness. Increasing the level of security can reduce scanning
aggressiveness, so select only the level of security necessary.
•
I 2 of 5 Security Level 0: This setting allows the imager to operate in its most aggressive state, while
providing sufficient security in decoding most in-spec bar codes.
•
I 2 of 5 Security Level 1: A bar code must be successfully read twice, and satisfy certain safety
requirements before being decoded. This default setting eliminates most misdecodes.
•
I 2 of 5 Security Level 2: Select this option with greater bar code security requirements if Security
Level 1 fails to eliminate misdecodes.
•
I 2 of 5 Security Level 3: If you selected Security Level 2, and misdecodes still occur, select this
security level. The highest safety requirements are applied. A bar code must be successfully read three
times before being decoded.
NOTE Selecting this option is an extreme measure against mis-decoding severely out-of-spec bar codes.
Selecting this level of security significantly impairs the decoding ability of the imager. If this level of
security is required, try to improve the quality of the bar codes.
I 2 of 5 Security Level 0
(0)
*I 2 of 5 Security Level 1
(1)
I 2 of 5 Security Level 2
(2)
I 2 of 5 Security Level 3
(3)
