xviii DS457-XX20004ZZWW Fixed Mount Imager Integration Guide
•
Chapter 8, SSI Interface describes how to set up the decoder with a Simple Serial Interface (SSI) host.
Use SSI to program the decoder via bar code menu or SSI hosts commands.
•
Chapter 9, Serial Interface describes how to set up the decoder with a serial host. Use the serial interface
to connect the decoder to point-of-sale devices, host computers, or other devices with an available serial
port (e.g., com port).
•
Chapter 10, USB Interface describes how to set how to set up the decoder with a USB host. The decoder
connects directly to a USB host, or a powered USB hub, and is powered by it.
•
Chapter 11, OCR Programming describes how to set up the digital scanner for OCR programming.
•
Chapter 12, Symbologies describes all symbology features and provides the programming bar codes
necessary for selecting these features for the decoder.
•
Chapter 13, Driver’s License Set Up (DS457-DL) describes how to program the DS457-DL imager to
read and use the data contained in the 2D bar codes on US driver's licenses and AAMVA compliant ID
cards.
•
Chapter 14, 123Scan and Software Tools describes the Zebra software tools available for customizing
scanner operation.
•
Appendix A, Standard Default Parameters provides a table of all host and miscellaneous defaults.
•
Appendix B, Country Codes provides bar codes for programming the country keyboard type for the USB
keyboard (HID) device and the keyboard wedge host.
•
Appendix C, Country Code Pages provides bar codes for selecting code pages for the country keyboard
type.
•
Appendix D, CJK Decode Control describes control parameters for Unicode/CJK (Chinese, Japanese,
Korean) bar code decode through USB HID Keyboard mode.
•
Appendix E, Programming Reference provides a table of AIM code identifiers, ASCII character
conversions, and keyboard maps.
•
Appendix F, Sample Bar Codes includes sample bar codes of various code types.
•
Appendix G, Numeric Bar Codes includes the numeric bar codes to scan for parameters requiring
specific numeric values.
•
Appendix H, ASCII Character Sets provides ASCII character value tables.
Notational Conventions
The following conventions are used in this document:
•
“Imager” refers to the DS457 imager
•
“Engine” or “imaging engine” refers to the SE4500 imaging engine.
•
Italics highlight chapters and sections in this and related documents
•
Bullets (•) indicate:
• action items
• lists of alternatives
• lists of required steps that are not necessarily sequential.
•
Sequential lists (e.g., those that describe step-by-step procedures) appear as numbered lists.
