Zebra DS457 Series - JPEG Quality and Size Value

7 - 20 DS457-XX20004ZZWW Fixed Mount Imager Integration Guide
JPEG Quality and Size Value
JPEG Quality = Parameter # 305 (SSI # F0h 31h)
JPEG Size = Parameter # 561 (SSI # F1h 31h)
If you select JPEG Quality Selector, scan the JPEG Quality Value bar code followed by 3 bar codes from
Appendix G, Numeric Bar Codes corresponding to a value from 5 to 100, where 100 represents the highest
quality image.
If you select JPEG Size Selector, scan JPEG Size Value followed by 3 bar codes from Appendix G, Numeric
Bar Codes corresponding to a value from 5 to 350 which represents the file size in multiples of 1024 bytes
(1K). For example, setting this value to 8 (008) permits the file size to be as large as 8192 bytes. The default is
160 (164K).
JPEG Quality Value
(Default: 065)
(5 - 100 Decimal)
JPEG Size Value
(Default: 040)
(5 - 150 Decimal)
