4 - 4 DS457-XX20004ZZWW Fixed Mount Imager Integration Guide
Dimensions 1.15 in. (29.2 mm) H x 2.30 in. (58.4 mm) W x 2.44 in. (62.0 mm) D
Weight 3.9 oz. (111.0 grams)
Interface 9-pin male D-sub supports USB (full speed) and TTL level RS-232
with RTS and CTS
Table 4-2
DS457 Technical Specifications at 23° C (Continued)
Item Description
Note: Environmental and/or tolerance parameters are not cumulative. Perform a thermal analysis
if the application is subject to an extreme temperature environment.
