Zebra DS457 Series User Manual

Imager Preferences 7 - 3
Snapshot Aiming Pattern 300 F0h 2Ch Enable 7-14
Image Cropping 301 F0h 2Dh Disable 7-15
Crop to Pixel Addresses 315, 316,
317, 318
F4h F0h 3Bh;
F4h F0h 3Ch;
F4h F0h 3Dh;
F4h F0h 3Eh
0 top, 0 left,
479 bottom, 751 right
7-16
Image Resolution 302 F0h 2Eh Full 7-17
Image Brightness (Target White) 390 F0h 86h 180 7-18
Image File Format Selection 304 F0h 30h JPEG 7-19
JPEG Image Options 299 F0h 2Bh Quality 7-19
JPEG Quality Value 305 F0h 31h 65 7-20
JPEG Size Value 561 F1h 31h 160 (164K) 7-20
Image Enhancement 564 F1h 34h Off 7-21
Image Edge Sharpening 664 F1h 98h Low 7-22
Image Contrast Enhancement 666 F1h 9Ah Enable 7-23
Image Rotation 665 F1h 99h 0 7-24
Bits per Pixel (BPP) 303 F0h 2Fh 8 BPP 7-25
Signature Capture 93 5Dh Disable 7-26
Signature Capture Image File Format
Selection
313 F0h 39h JPEG 7-27
Signature Capture Bits per Pixel (BPP) 314 F0h 3Ah 8 BPP 7-28
Signature Capture Width 366 F4h F0h 6Eh 400 7-28
Signature Capture Height 367 F4h F0h 6Fh 100 7-29
Signature Capture JPEG Quality 421 F0h A5h 65 7-29
Video Mode Format Selector 916 F2h 94h JPEG 7-30
Video View Finder 324 F0h 44h Disable 7-30
Target Video Frame Size 328 F0h 48h 2200 bytes 7-31
Video View Finder Image Size 329 F0h 49h 1700 bytes 7-31
Video Resolution 667 F1h 9Bh 1/4 resolution 7-32
Table 7-1 Imager Preferences Default Table (Continued)
Parameter
Parameter
Number
SSI Number Default
Page
Number

Zebra DS457 Series Specifications

General

Connectivity	USB, RS-232
Decode Capability	1D, 2D, PDF417, Postal Codes
Scan Rate	Up to 60 scans per second
Supported Barcode Types	UPC/EAN, Code 39, Code 128, QR Code, Data Matrix, PDF417, Postal Codes
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
Humidity	5% to 95% (non-condensing)
Power Consumption	2.5 W (typical)
