Settings
170
TCPDump Module
The TCPDump Module captures tcp data that happens over the device’s networks.
• Enable Module - Enables logging for this module.
• Log path - Specifies the location to store the TCPDump output log files.
• Base filename - Specifies the base filename to use when storing the TCPDump files. The index number of
the current log file will be appended to this filename.
• Tcpdump file size - Specifies the maximum file size, in megabytes, for each log file created.
• Tcpdump file count - Specifies the number of log files to cycle through when storing the network traces.
Tombstone Module
The Tombstone Module collects tombstone (Linux Native Crashes) logs from the device.
• Enable Module - Enables logging for this module.
• Log path - Specifies the location to store the Tombstone output log files.
• Collect Historic tombstones -
Configuration File
RxLogger configuration can be set using an XML file. The config.xml configuration file is located on the microSD
card in the
RxLogger\config folder. Copy the file from the device to a host computer using a USB connection. Edit
the configuration file and the replace the .XML file on the device. There is no need to stop and restart the RxLogger
service since the file change is automatically detected.
Enabling Logging
To enable logging:
1. Swipe the screen up and select .
2. Touch Start.
3. Touch .
Disabling Logging
To disable logging:
1. Swipe the screen up and select .
2. Touch Stop.
3. Touch .
Extracting Log Files
1. Connect the device to a host computer using an USB connection.
2. Using a file explorer, navigate to the RxLogger folder.
3. Copy the file from the device to the host computer.
4. Disconnect the device from the host computer.
