Zebra MC33 Series - Ethernet Settings; Configuring Ethernet Proxy Settings

Accessories
42
Figure 17 Daisy-chaining 5-Slot Ethernet ShareCradles
5. Connect additional cradles as described in step 3 and 4.
Ethernet Settings
The following settings can be configured when using Ethernet communication:
• Proxy Settings
• Static IP.
Configuring Ethernet Proxy Settings
The MC33XX includes Ethernet cradle drivers. After inserting the MC33XX, configure the Ethernet connection:
1. Swipe down from the status bar to open the quick access panel and then touch .
2. Touch Ethernet.
3. Slide the switch to the ON position.
4. Place the MC33XX into the Ethernet cradle slot.
5. Touch and hold eth0 until the menu appears.
6. Touch Modify Proxy.
7. Touch the Proxy drop-down list and select Manual.
To Power Supply
To Next Cradle
To Power Supply
To Switch
Secondary Port
Primary Port
