Zebra MC33 Series Integrator Guide

Accessories
66
MC33XX-R Rubber Boot
The rubber boot provides additional protection to the MC33XX-R. The rubber boot is comprised of two pieces; one
for the mobile computer and one for the turret cup.
To attach the rubber boot:
1. Insert the rubber boot for the turret cup into the rubber boot for the mobile computer, to form a single piece, if it
is not already attached.
Figure 38 Two Piece Rubber Boot
2. Slide the top of the MC33XX-R into the top of the rubber boot.
Figure 39 Attach Top of Rubber Boot
3. Grasp the bottom of the rubber boot and place over the bottom of the MC33XX-R.

Zebra MC33 Series Specifications

General

Connectivity	USB 2.0, Bluetooth
Touch Panel	Capacitive, glove and wet touch support
Keypad Options	Touchscreen or physical keypad
Scanning	1D/2D barcode scanning
Wireless LAN	IEEE 802.11 a/b/g/n/ac
Operating Temperature	-20° C to 50° C
