Zebra MC33 Series Integrator Guide

Technical Specifications
238
SE965 Decode Zone
The table below lists the typical distances for selected barcode densities. The minimum element width (or “symbol
density”) is the width in mils of the narrowest element (bar or space) in the symbol.
Roll 360°
Pitch Angle +/- 60° from normal
Skew Tolerance +/- 60° from normal
Ambient Light Sunlight: 10,000 ft. candles (107,639 lux)
Laser Aiming Element Laser Wavelength: 655 nm
Central Dot Optical Power: 0.6 mW (Class 2 IEC60825:2014)
Illumination System LEDs: Hyper Red 660nm
Supported Symbologies
1D Chinese 2 of 5, Codabar, Code 11, Code 128, Code 39, Code 93,
Discrete 2 of 5, EAN-8, EAN-13, GS1 DataBar, GS1 DataBar
Expanded, GS1 DataBar Limited, Interleaved 2 of 5, Korean 2 of
5, MSI, TLC 39, Matrix 2 of 5, Trioptic, UPCA, UPCE, UPCE1,
Web Code.
2D Australian Postal, Aztec, Canadian Postal, Composite AB,
Composite C, Data Matrix, Dutch Postal, Japan Postal,
Maxicode, Micro PDF, Micro QR, PDF, QR Code, UK Postal, US
Planet, US Postnet, US4State, US4State FICS.
Table 21 MC33XX Technical Specifications (Continued)
Item Description
Table 22 SE965 Decode Distances
Symbol Density/
Barcode Type
Barcode Content/ Contrast
Note 1
Typical Working Ranges
Near Far
5.0 mil
Code 128
1234
80% MRD
1.2 in
3.05 cm
7.7 in
19.56 cm
5.0 mil
Code 39
ABCDEFGH
80% MRD
1.2 in
3.05 cm
12.5 in
31.75 cm
7.5 mil
Code 39
ABCDEF
80% MRD
1.1 in
2.79 cm
18.5 in
46.99 cm
10 mil
Code 128
1234
80% MRD
1.2 in
3.05 cm
Note 3
19.0 in
48.26 cm
13 mil
100% UPC
012345678905
80% MRD
1.6 in
4.06 cm
27.0 in
68.58 cm
