Zebra ZXP Series 3 Service Manual

8 Zebra ZXP Series 3 Card Printer Service Manual P1061317-002
1: General Description
Specifications
Supplies Specifications
The ZXP Series 3 printer is designed to work only with Zebra ZXP Series 3 True Colours
ix Series ribbons.
• Zebra ix Series media-intelligent technology automatically detects and authenticates
the ribbon.
• Integrated cleaning roller included on each ribbon.
• Media Starter Kit (single-sided): 1 YMCKO ribbon, 200 30-mil PVC cards,
1 cleaning roll.
• Cleaning Kit: 4 print engine cleaning cards and 4 feeder cleaning cards, 1,000 images.
True Colours ix Series, ZXP Series 3 Ribbon options:
Drivers Supported
Microsoft Windows Certified Printer Drivers:
• Windows XP, Vista, Server 2003, Server 2008
• Windows 7 (32-bit and 64-bit compatible)
• Windows 8 (32-bit and 64-bit compatible)
Go to
www.zebra.com for up-to-date listing of supported environments
Physical Specifications (standard model)
• Height: 9.3 in (236 mm)
• Width: 7.9 in (200.7 mm)
• Depth: 14.5 in (368 mm)
• Weight: 12.2 lbs (5.53 kg)
Ribbon Description
Standard Cartridge
Image Count
New High Capacity
Eco Cartridge Image
Count (1)
YMCKO 200 280
1/2 YMCKO 250 400
YMCKOK 165 230
KdO 500 700
KrO 500 700
Black Monochrome 1000 2000
Red Monochrome 1000 1700
Blue Monochrome 1000 1700
Gold Monochrome 1000 1600
Silver Monochrome 1000 1600
White Monochrome 850 1400
(1) Requires Firmware Release 2.0 or greater

Zebra ZXP Series 3 Specifications

General

Color	No
Card size	54 x 86 mm
Card types	Magnetic stripe (ISO 7811), PVC, PVC Composite, Smart card
Card feeder	Yes
Print technology	Dye-sublimation
Maximum resolution	300 DPI
Print speed (color)	180 card/h
Print speed (monochrome)	750 card/h
Printing media thickness	762 µm
Duplex print speed (color)	140 card/h
Display	LCD
Certification	FCC, CE, UL, CUL
Product color	Grey, White
Internal memory	32 MB
Built-in barcodes	EAN13, EAN8, Interleaved 2/5, PDF417, UPC-A
Total input capacity	100 sheets
Display number of characters	16
Compatible operating systems	Windows
Storage temperature (T-T)	-5 - 70 °C
Operating temperature (T-T)	15 - 30 °C
Storage relative humidity (H-H)	20 - 70 %
Operating relative humidity (H-H)	20 - 65 %
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Interface	USB
Optional connectivity	Ethernet, USB 2.0

Weight and Dimensions

Weight	5530 g
Dimensions (WxDxH)	201 x 368 x 309 mm
